14 www.goodmanmfg.com SS-GPC14H
SS-GPC14H www.goodmanmfg.com 15
Product SPecificationS
Product SPecificationS
exPanded CoolinG data — GPC1460H41**
Outdoor Ambient Temperature
65 75 85 95 105 115
Entering Indoor Wet Bulb Temperature
IDB Airflow 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71
70
1900
MBh 56.3 58.4 64.0 - 55.0 57.0 62.5 - 53.7 55.7 61.0 - 52.4 54.3 59.5 - 49.8 51.6 56.5 - 46.1 47.8 52.4 -
S/T 0.71 0.60 0.41 - 0.74 0.62 0.43 - 0.76 0.63 0.44 - 0.78 0.65 0.45 - 0.81 0.68 0.47 - 0.82 0.69 0.47 -
∆ T 21 18 14 - 21 18 14 - 21 18 14 - 21 18 14 - 21 18 14 - 19 17 13 -
kW 3.70 3.78 3.91 - 4.00 4.09 4.23 - 4.26 4.36 4.51 - 4.49 4.60 4.75 - 4.69 4.80 4.96 - 4.86 4.97 5.14 -
Amps 15.7 16.0 16.5 - 16.9 17.2 17.8 - 18.2 18.6 19.2 - 19.4 19.9 20.5 - 20.6 21.1 21.7 - 21.7 22.3 23.0 -
HI PR 238 256 271 - 267 288 304 - 304 327 345 - 346 373 393 - 390 419 443 - 430 463 489 -
LO PR 108 115 125 - 114 121 132 - 118 126 137 - 124 132 144 - 130 139 151 - 135 143 156 -
1700
MBh 54.7 56.7 62.1 - 53.4 55.4 60.7 - 52.2 54.1 59.2 - 50.9 52.7 57.8 - 48.3 50.1 54.9 - 44.8 46.4 50.9 -
S/T 0.68 0.57 0.39 - 0.71 0.59 0.41 - 0.72 0.60 0.42 - 0.75 0.62 0.43 - 0.78 0.65 0.45 - 0.78 0.65 0.45 -
∆ T 21 19 14 - 22 19 14 - 22 19 14 - 22 19 14 - 22 19 14 - 20 17 13 -
kW 3.67 3.75 3.88 - 3.97 4.06 4.19 - 4.23 4.32 4.47 - 4.46 4.56 4.71 - 4.65 4.76 4.92 - 4.82 4.93 5.10 -
Amps 15.6 15.9 16.4 - 16.7 17.1 17.6 - 18.1 18.5 19.1 - 19.2 19.7 20.3 - 20.4 20.9 21.5 - 21.6 22.1 22.8 -
HI PR 236 254 268 - 265 285 301 - 301 324 342 - 343 369 390 - 386 415 438 - 426 459 484 -
LO PR 107 114 124 - 113 120 131 - 117 125 136 - 123 131 143 - 129 137 150 - 133 142 155 -
1500
MBh 50.5 52.3 57.3 - 49.3 51.1 56.0 - 48.1 49.9 54.7
- 47.0 48.7 53.3 - 44.6 46.2 50.7 - 41.3 42.8 46.9 -
S/T 0.66 0.55 0.38 - 0.68 0.57 0.39 - 0.70 0.58 0.40 - 0.72 0.60 0.42 - 0.75 0.62 0.43 - 0.75 0.63 0.44 -
∆ T 22 19 14 - 22 19 14 - 22 19 15 - 22 19 15 - 22 19 14 - 20 18 13 -
kW 3.58 3.66 3.78 - 3.87 3.95 4.08 - 4.12 4.21 4.35 - 4.34 4.44 4.59 - 4.53 4.63 4.79 - 4.69 4.80 4.97 -
Amps 15.2
15.5 16.0 - 16.3 16.7 17.2 - 17.6 18.0 18.6 - 18.7 19.2 19.8 - 19.9 20.3 21.0 - 21.0 21.5 22.2 -
HI PR 229 246 260 - 257 276 292 - 292 314 332 - 333 358 378 - 374 403 425 - 413 445 470 -
LO PR 103 110 120 - 109 116 127 - 114 121 132 - 119 127 139 - 125 133 145 - 129 138 150 -
75
1900
MBh 57.3 59.0 63.9 68.5 56.0 57.6 62.4 66.9 54.6 56.3 60.9 65.3 53.3 54.9 59.4 63.8 50.6 52.1 56.4 60.6 46.9 48.3 52.3 56.1
S/T 0.81 0.73 0.55 0.35 0.84 0.75 0.57 0.37 0.86 0.77 0.58 0.38 0.89 0.80 0.60 0.39 0.92 0.83 0.63 0.40 0.93 0.83 0.63 0.41
∆ T 24 22 18 12 24 22 18 13 24 22 18 13 24 22 18 13 24 22 18 12 22 21 17 12
kW 3.73 3.82 3.94 4.07 4.03 4.12 4.26 4.41 4.30 4.40 4.55 4.70 4.53 4.64 4.79 4.96 4.73 4.84 5.01 5.18 4.90 5.02 5.19 5.37
Amps 15.8 16.2 16.7 17.2 17.0 17.4 17.9 18.6 18.4 18.8 19.4 20.1 19.6 20.0 20.7 21.4 20.8 21.3 21.9 22.7 21.9 22.5 23.2 24.0
HI PR 241 259 273 285 270 291 307 320 307 330 349 364 350 376 397 415 393 423 447 466 435 468 494 515
LO PR 109 116 126 135 115 122 134 142 120 127 139 148 126 134 146 155 132 140 153 163 136 145 158 168
1700
MBh 55.6 57.3 62.0 66.5 54.3 55.9 60.6 65.0 53.0 54.6 59.1 63.4 51.8 53.3 57.7 61.9 49.2 50.6 54.8 58.8 45.5 46.9 50.8 54.5
S/T 0.77 0.69 0.52 0.34 0.80 0.72 0.54 0.35 0.82 0.74 0.56 0.36 0.85 0.76 0.58 0.37 0.88 0.79 0.60 0.38 0.89 0.80 0.60 0.39
∆ T 25 23 19 13 25 23 19 13
25 23 19 13 25 23 19 13 25 23 19 13 23 21 18 12
kW 3.70 3.79 3.91 4.04 4.00 4.09 4.23 4.37 4.26 4.36 4.51 4.66 4.49 4.60 4.75 4.92 4.69 4.80 4.96 5.14 4.86 4.97 5.14 5.32
Amps 15.7
16.0 16.5 17.1 16.9 17.3 17.8 18.4 18.2 18.6 19.2 19.9 19.4 19.9 20.5 21.2 20.6 21.1 21.7 22.5 21.7 22.3 23.0 23.8
HI PR 238 256 271 282 267 288 304 317 304 327 346 360 346 373 394 410 390 419 443 462 430 463 489 510
LO PR 108 115 125 133 114 121 132 141 118 126 137 146 124 132 144 154 130 139 151 161 135 143 157 167
1500
MBh 51.3 52.9 57.2 61.4 50.2 51.6 55.9 60.0 49.0 50.4 54.6 58.6 47.8 49.2 53.2 57.1 45.4 46.7 50.6 54.3 42.0 43.3 46.8 50.3
S/T 0.75 0.67 0.51 0.33 0.77 0.69 0.52 0.34 0.79 0.71 0.54 0.35 0.82 0.73 0.55 0.36 0.85 0.76 0.58 0.37 0.86 0.77 0.58 0.37
∆ T 25 23 19 13 25 23 19 13 26 24 19 13 26 24 19 13 25 23 19 13 24 22 18 12
kW 3.61 3.69 3.81 3.94 3.90 3.99 4.12 4.26 4.15 4.25 4.39 4.54 4.38 4.48 4.63 4.79 4.57 4.67 4.83 5.00 4.73 4.84 5.01 5.18
Amps 15.3 15.6 16.1 16.7 16.4 16.8 17.3 17.9 17.8 18.2 18.7 19.4 18.9 19.3 19.9 20.7 20.0 20.5 21.2 21.9 21.2 21.7 22.4 23.2
HI PR 231 249 263 274 259 279 295 307 295 317 335 350 336 361 382 398 378 407 429 448 418 449 474 495
LO PR 105 111 121 129 110 118 128 137 115 122 133 142 121 128 140 149 126 134 147 156 131 139 152 162
IDB = Entering Indoor Dry Bulb Temperature Shaded area reects ACCA (TVA) condions. kW = total system power
High and low pressures are measured at the liquid and sucon access ngs. Amps: Unit amps (comp.+ evaporator + condenser fan motors)
