Product SPecificationS
Product SPecificationS
SpecificationS (cont.)
GPC14
42H41C*
GPC14
42H41D*
GPC14
48H41C*
GPC14
48H41D*
GPC14
60H41C*
GPC14
60H41D*
Cooling Capacity
Cooling Capacity (BTU/h) 40,000 40,000 46,000 46,000 57,500 57,500
Sensible BTU/h 30,400 30,400 35,300 35,300 40,800 40,800
SEER / EER 14.0 / 12.0 14.0 / 12.0 14.0 / 12.0 14.0 / 12.0 14.0 / 12.0 14.0 / 12.0
Decibels 78 78 80 80 80 80
AHRI Numbers
5677888 6892358 5677889 6892361 5677890 6892362
Evaporator Motor
Type EEM EEM EEM EEM EEM EEM
Wheel (D x W) 10 x 8 10 x 8 10 x 8 10 x 8 11 x 8 11 x 8
Cooling CFM 1,200 1,200 1,600 1,600 1,600 1,600
Fan-Only CFM 1,200 1,200 1,400 1,400 1,700 1,700
RLA 2.9 2.9 2.9 2.9 2.9 2.9
No. of Speeds 5 5 5 5 5 5
Horsepower - RPM ½ - 1050 ½ - 1050 ¾ - 1050 ¾ - 1050 ¾ - 1050 ¾ - 1050
Evaporator Coil
Face Area (²) 6.2 6.20 6.2 6.20 7 7.00
Rows Deep/ Fins per Inch 4/ 14 4/ 14 4/ 14 4/ 14 4/ 14 4/ 14
Indoor Orice Size 0.072 0.072 0.078 0.078 0.086 0.086
Filter Size (") (2) 20 x 20 x 1 (2) 20 x 20 x 1 (2) 20 x 20 x 1 (2) 20 x 20 x 1 (2) 20 x 25 x 1 (2) 20 x 25 x 1
All-aluminum coil X X X X X X
Drain Size (NPT) ¾" ¾" ¾" ¾" ¾" ¾"
Refrigerant Charge (oz.) 94 94 90 90 110 110
Condenser Fan / Coil
Horsepower - RPM ¼ - 1075 ¼ - 1075 ¼ - 1075 ¼ - 1075 ¼ - 1075 ¼ - 1075
RLA/LRA 1.4 / 2.9 1.4 / 2.9 1.4 / 2.9 1.4 / 2.9 1.4 / 2.9 1.4 / 2.9
Fan Diameter/ # Fan Blades 22 / 4 22 / 4 22 / 4 22 / 4 22 / 4 22 / 4
Face Area (²) 16 16 19.5 19.5 17 17
Rows Deep/ Fins per Inch 1 / 28 1 / 28 1 / 28 1 / 28 2 /28 2 /28
Compressor
Quanty / Type 1 / Scroll 1 / Scroll 1 / Scroll 1 / Scroll 1 / Scroll 1 / Scroll
Stage Single Single Single Single Single Single
Compressor RLA/LRA 17.9 / 112 17.9 / 112 19.9 / 109 19.9 / 109 26.4 / 134 26.4 / 134
Electrical Data
Voltage-Phase (60 Hz) 208/230-1 208/230-1 208/230-1 208/230-1 208/230-1 208/230-1
Indoor Blower FLA 2.9 3.8 2.9 5.4 2.9 5.4
Outdoor Fan RLA 1.4 1.4 1.4 1.4 1.4 1.4
Total Unit Amps 22.2 23.1 24.2 26.7 30.7 33.2
Min. Circuit Ampacity¹ 26.6 28 29.1 32 37.3 40
Max. Overcurrent Protecon (amps)² 40 45 45 50 60 60
Ship Weight (lbs) 360 360 370 370 375 375
Operating Weight (lbs) 365 365 375 375 380 380
¹ Wire size should be determined in accordance with Naonal Electrical Codes. Extensive wire runs will require larger wire sizes.
² May use fuses or HACR-type circuit breakers of the same size as noted.
Note: Always check the S&R plate for electrical data on the unit being installed.
