SS-GPC14H www.goodmanmfg.com 11/13
Supersedes 7/13
GPC14H
2- to 5-ton PaCkaGed air Conditioner
uP
to 14 Seer
CoolinG CaPaCity: 24,000 - 57,500 Btu/H
* Complete warranty details available from your local dealer or at www.goodmanmfg.com. To
receive the 10-Year Parts Limited Warranty, online registration must be completed within 60 days
of installation. Online registration is not required in California or Quebec.
Contents
Nomenclature ....................................... 2
Product Specications .......................... 3
Expanded Cooling Data ........................ 5
Airow Data ........................................ 17
Heater Kit Specications .................... 19
Wiring Diagram ................................... 21
Dimensions ......................................... 22
Accessories .......................................... 23
Standard Features
Energy-efcient compressor
with internal relief valve
EEM blower motor
Quiet horizontal discharge
Copper tube / aluminum n condenser coil
Totally enclosed, permanently
lubricated condenser fan motor
Fully charged system
5 kW to 20 kW electric heat kit avail-
able as a eld-installed option
AHRI Certied; ETL Listed
Cabinet Features
Heavy-gauge galvanized-steel cabinet
with attractive Architectural Gray
powder-paint nish
Fully insulated blower compartment
with convenient access panels
Louvered condenser coil protection
One footprint; three heights
