– 44 –
Using #70 Relay Menu Mode
General Information
Your system may be set up so that certain lights or other devices can
be turned on or off by using the #70 command from either a keypad or
a telephone keypad (if 4285 or 4286 VIP module is used). Ask your
installer if this has been done in your system.
To activate relays from a keypad, enter 4-digit security code + [#]
+70. Follow the keypad prompts described below.
To activate relays using a telephone and 4285 or 4286 VIP
module, first dial the 2-digit phone access code. When the system
acknowledges the access, enter 4-digit security code + [#] + 70. The
following prompts/voice responses will begin.
ENTER DEVICE NO.
00=QUIT 01
Voice: "ENTER DEVICE CODE NOW"
Enter the 2-digit number of the device to be
activated.
Note that if an invalid number is entered, the
system will simply ask you to reenter the
number.
NN DEVICE IS OFF
HIT 0=OFF , 1=ON
Voice: "voice descriptor DEVICE nn ON/OFF.
FOR voice descriptor ON ENTER 1, FOR voice
descriptor OFF ENTER 0"
Press 0 or 1 to turn the device off or on
respectively.
"nn" represents the 2-digit device number and
voice descriptor is the relay voice descriptor
programmed by the installer.
