Crestron CLS-C6 Series iLux
™
Integrated Lighting Systems
Operating Modes
After installation, the CLS-C6 operates in one of three modes:
• Standard mode: this is the default mode; buttons are typically used to recall
scenes, although they can be reprogrammed by the dealer for other
functions.
• Lights mode: this mode is used to manually adjust lighting loads.
• Shades mode: this mode is used to manually control shade groups.
The following descriptions do not include additional functionality made possible by
dealer programming. Those functions are beyond the scope of this guide.
Standard Mode
By default, the six function buttons recall scenes 1 - 6. As a scene is recalled, the
lights fade (change from one level to another) in a specified time, and any shades in
the scene go to their specified levels.
The ON and OFF buttons recall the On and Off scenes, respectively. By default, the
On scene will set all lights to full on. The Off scene will always set all lights to full
off.
While fading, the LED for the selected scene recall button blinks, and then stays on
when fade is complete; the two-digit display shows the time remaining; If you press
the selected scene recall button again before fade is complete, the lights immediately
go to their assigned levels and the LED turns solid.
The six bargraphs always show the current level of each lighting load.
When all lights are off, the LEDs for all function buttons glow dimly to make it easy
to locate the panel in the dark.
The up/down button acts as a lights master, adjusting the level of all dimmable
lighting loads simultaneously. Pressing the top of the button raises the lights;
pressing the bottom of the button lowers them.
You can also select functions using an optional remote keypad or IR remote control.
Lights Mode
Lights mode lets you manually adjust any of the six lighting loads.
To enter Lights mode, press the Lights button. The LED will light, and the six
function buttons can now be used to adjust the six lighting loads.
• Press the right side of the function buttons to raise the lights; press the left
side to lower the lights.
• The six bargraphs show the current level of each lighting load.
• While a particular lighting load is being adjusted, the two-digit display
shows its level. (“oF” indicates fully off; “on” indicates fully on; “1” – “99”
indicate percent of the full on level.) Press the center of a function button to
check light level without adjusting.
• The up/down button acts as an all lights master in this mode. Press the top
of the button to raise the lights; press the bottom of the button to lower the
lights.
The ON and OFF buttons operate normally while in Lights mode.
User Guide - DOC. 6395B iLux
™
Integrated Lighting Systems: CLS-C6 Series • 5
