33
Figure 25: Electrode / Head Setting for
Beckett Burner
Figure 25A: Electrode / Head Setting for
Carlin EZ-1HP Burner
Table 7A: Becket AFG Burner
Table 7: Beckett AFG, AF, & SF Burners
Table 7B: Carlin EZ-2HP Burner
Boiler Model Firing Rate Manufacturer GPH Angle Type Head Bar Air Band Setting
RSA85 .85
Delavan
.75
60°
A .75 .60
RSAH85 .75 .65
W
.60/.65 .50
RSA110 1.10 .90
.85/1.00
.75
RSAH110 1.00 .85 .60
RSA125 1.25 1.10
A
1.10/1.25 .90
RSAH125 1.10 .90 .85/1.00 .65
RSA135 1.35 1.20 W
1.10/1.25
.85
RSAH135 1.25 1.10 A .85
Boiler Model
Firing Rate
(GPH)
Hago Nozzle
Air Settings
Shutter Band
Head
(stop screw)
Pump Pressure
RSAH85 .75 .65 x 80B 6
0 N/A 140
RSAH110 1.0 .85 x 80B 7
RSAH125 1.1 .90 x 80B 7
RSAH135 1.25 1.0 x 80B 9
Boiler Model
Firing Rate
(GPH)
Hago Nozzle
Air Settings
Shutter Band Head (stop screw) Pump Pressure
RSA85* .85 .75 x 80B 10
0 N/A
140
RSA110 1.10 .90 x 80B 8
RSA125 1.25 1.0 x 80B 7
RSA135 1.35 1.10 x 80B 9
RSA170 1.70 1.65 x 80A 7
100
RSA195 1.95 2.00 x 80B 7
RSA240 2.40 2.50 x 80B 7
RSA285 2.85 3.00 x 80B 7
* Equipped with low ring rate bafe
