8. Burnham EC5000 Circulator Zoned System – Refer
to Figure 18 of this manual for the electrical diagram
for this type of system. Wire the system as indicated
in that diagram. Refer to the manual provided with
the Burnham EC5000 Control for control operation
and setup details.
9. Burnham EC5000 Zone Valve Zoned System
– Refer to Figure 19 of this manual for the electrical
diagram for this type of system. Wire the system
as indicated in that diagram. Refer to the manual
provided with the Burnham EC5000 for control
operation and setup details.
NOTICE
The Burnham EC5000 Control includes a water temperature sensor. Mount this sensor to the system supply
piping.
