2. Lamp and Lamp House
Image 2-4
2. Push the Lamp House forw ard until it slides fully into the projector. The positioning pins mu
st match the holes in the Lamp House.
3. Secure the 3 captive screws on the Lamp House.
Image 2-5
4. Install the right projector cover. See the installation manual of the projector.
5. Plug in the power cord at the projector back side.
Note: While starting up the projector, the electronics detect if a Lamp House is installed. If no Lamp House is installed, it is not
possible to start up the projector.
2.3 Realignment of the lamp in the Lamp House
WARNING: The procedures below may only be performed by Barco trained and qualified technicians.
It is recommended to reali
gn the Z-axis of the lamp af ter the first run time of 100 and 200 h ours.
R5905109 LAMP HOUSE WITH 2.5 KW LAMP 27/05/2014 7
