Initialization
There are two ways that the printer can be initialized (returned to
the default settings) through the hardware and one through the
software. These are described in the following table:
Hardware initialization
Software initialization
. The power is turned on.
. The printer receives an INIT signal at the paral-
lel interface (pin 31 goes LOW).
. The software sends the ESC @ (initialize the
printer) command.
Default settings
The table below shows the default conditions that become valid
when the printer is initialized.
Item
Reset to:
Top of form position
Current paper position
Left and right margins
Cancelled
Line spacing
1/6-inch line spacing
Vertical tab position
Cleared
Horizontal tab positions
Every eight characters
VFU channel
Channel 0
Font selection
The current SelecType setting
Condensed mode
The current SelecType setting
Character spacing
The current DIP switch setting
Justification
Left justification
Special printing effects
Cancelled
Graphic mode assignment
ESCK=ESC*O,ESCL=ESC*1,
ESC Y = ESC *2, ESC Z = ESC * 3
Technical Specification
8-15
