Corner Tri Quad
Item Part No. Description Qty Qty Qty
1 S08-432TMA TMA Dual Valve Assembly (includes 7-13 ) 1 — —
2 S08-432TL TL Dual Valve Assembly (includes 8-14 ) 1 — —
3 S08-433TMA TMA Tri Valve Assembly (includes 7-13 ) — 1 —
4 S08-433TL TL Tri Valve Assembly (includes 8-14 ) — 1 —
5 S08-434TMA TMA Quad Valve Assembly (includes 7-13 ) — — 1
6 S08-434TL TL Quad Valve Assembly (includes 8-14 ) — — 1
7 S01-520 Vernatherm Valve, 4 GP 1 1 1
8 140-928 Bracket, Ganged Valve 1 1 1
9 P18-054 Screw 10-24 x 3/8 PN 2 2 2
10 S07-083 BIR3 Valve, through (includes 15-17) 1 2 3
11 S07-083A BIR3 Valve, closed (includes 15-17) 1 1 1
12 110-231 Compression Nut, 1/4" 2 3 4
13 160-447 Screw 8-16 x 5/8 PN 2 3 4
14 S39-685 Adapter, Valve Inlet 1 1 1
16 S83-178 Circuit Board 2 3 4
17 160-451 Screw #6-19 x 3/4 2 3 4
18 S83-177 Battery Holder 2 3 4
19 261-010 Lithium Battery, Type DL223A or Equivalent 2 3 4
20 S45-2083 Battery Prepack (includes 18,19) 2 3 4
Parts List — Air Metering Valve Assembly
