FORM 150.63-EG1
Ratings - R22 (SI Units)
NOTES:
1. SST = Saturated Suction Temperature
2. kWo = Unit kW Cooling Capacity Output
3. kWi = Compressors kW Input
4. COP = Coefcient of Performance (based on compressor and fan input kW)
YCUL0016EC
AIR TEMPERATURE ON - CONDENSER (°C)
LCWT
(°C)
25°C 30°C 35°C 40°C 45°C 50°C
KWo KWi COP KWo KWi COP KWo KWi COP KWo KWi COP KWo KWi COP KWo KWi COP
2.0
49.3 11.2 3.5 47.0 12.3 3.1 44.9 13.7 2.7 42.8 15.2 2.4 40.4 16.8 2.1 37.8 18.6 1.8
3.0
50.9 11.2 3.6 48.6 12.4 3.2 46.5 13.7 2.8 44.2 15.2 2.5 41.8 16.9 2.1 39.1 18.7 1.8
4.0
52.6 11.3 3.7 50.3 12.5 3.3 48.0 13.8 2.9 45.8 15.3 2.5 43.3 17.0 2.2 40.5 18.8 1.9
5.0
54.4 11.4 3.8 52.0 12.5 3.4 49.7 13.9 3.0 47.3 15.4 2.6 44.8 17.1 2.3 41.9 18.9 1.9
6.0
56.2 11.4 4.0 53.7 12.6 3.5 51.4 14.0 3.1 48.9 15.5 2.7 46.3 17.1 2.3 43.3 19.0 2.0
7.0
58.1 11.5 4.1 55.5 12.7 3.6 53.1 14.0 3.2 50.6 15.5 2.8 47.8 17.2 2.4 23.3 8.4 2.1
8.0
60.0 11.6 4.2 57.4 12.8 3.7 54.8 14.1 3.2 52.2 15.6 2.8 49.4 17.3 2.5 24.1 8.5 2.1
9.0
62.0 11.7 4.3 59.3 12.9 3.8 56.7 14.2 3.3 54.0 15.7 2.9 51.1 17.4 2.5 25.0 8.5 2.2
10.0
64.0 11.8 4.4 61.2 12.9 3.9 58.5 14.3 3.4 55.8 15.8 3.0 52.8 17.5 2.6 25.8 8.5 2.3
11.0
66.1 11.8 4.5 63.2 13.0 4.0 60.4 14.4 3.5 57.6 15.9 3.1 54.5 17.6 2.7 26.7 8.5 2.4
12.0
68.2 11.9 4.6 65.3 13.1 4.1 62.4 14.5 3.6 59.5 16.0 3.2 56.3 17.7 2.8 27.6 8.6 2.4
YCUL0026EC
AIR TEMPERATURE ON - CONDENSER (°C)
LCWT
(°C)
25°C 30°C 35°C 40°C 45°C 50°C
KWo KWi COP KWo KWi COP KWo KWi COP KWo KWi COP KWo KWi COP KWo KWi COP
2.0
68.4 16.0 3.6 65.3 17.7 3.2 62.0 19.6 2.8 58.7 21.7 2.4 55.2 24.0 2.1 51.7 26.4 1.8
3.0
70.7 16.1 3.7 67.5 17.9 3.3 64.1 19.8 2.8 60.6 21.9 2.5 57.1 24.1 2.1 53.5 26.6 1.8
4.0
73.0 16.2 3.8 69.7 18.0 3.4 66.2 19.9 2.9 62.6 22.0 2.5 59.0 24.3 2.2 55.3 26.8 1.9
5.0
75.4 16.3 3.9 71.9 18.1 3.4 68.3 20.0 3.0 64.7 22.1 2.6 60.9 24.4 2.2 57.2 26.9 1.9
6.0
77.8 16.5 4.0 74.2 18.2 3.5 70.5 20.2 3.1 66.8 22.3 2.7 62.9 24.6 2.3 31.2 11.7 2.2
7.0
80.2 16.6 4.1 76.5 18.4 3.6 72.8 20.3 3.2 68.9 22.4 2.7 64.9 24.8 2.4 32.3 11.8 2.2
8.0
82.7 16.7 4.2 78.9 18.5 3.7 75.0 20.4 3.2 71.0 22.6 2.8 67.0 24.9 2.4 33.4 11.8 2.3
9.0
85.2 16.8 4.3 81.4 18.6 3.8 77.4 20.6 3.3 73.2 22.7 2.9 69.1 25.1 2.5 34.4 11.9 2.4
10.0
87.8 17.0 4.4 83.8 18.8 3.9 79.7 20.7 3.4 75.5 22.9 2.9 71.2 25.3 2.5 35.6 11.9 2.4
11.0
90.5 17.1 4.5 86.4 18.9 4.0 82.1 20.9 3.5 77.8 23.1 3.0 73.4 25.4 2.6 36.7 11.9 2.5
12.0
93.2 17.3 4.6 88.9 19.1 4.1 84.6 21.1 3.5 80.1 23.2 3.1 75.6 25.6 2.7 37.9 12.0 2.6
YCUL0030EC
AIR TEMPERATURE ON - CONDENSER (°C)
LCWT
(°C)
25°C 30°C 35°C 40°C 45°C 50°C
KWo KWi COP KWo KWi COP KWo KWi COP KWo KWi COP KWo KWi COP KWo KWi COP
2.0
84.2 20.2 3.7 80.7 22.1 3.2 76.9 24.4 2.8 72.9 26.8 2.5 68.6 29.6 2.1 63.8 32.7 1.8
3.0
87.0 20.3 3.8 83.4 22.3 3.3 79.5 24.5 2.9 75.4 27.0 2.5 70.9 29.8 2.2 66.1 32.9 1.9
4.0
89.8 20.5 3.9 86.1 22.4 3.4 82.1 24.7 3.0 77.9 27.2 2.6 73.4 30.0 2.2 68.5 33.0 1.9
5.0
92.8 20.6 4.0 88.9 22.6 3.5 84.8 24.8 3.1 80.5 27.3 2.7 75.8 30.1 2.3 70.9 33.2 2.0
6.0
95.7 20.8 4.1 91.8 22.7 3.6 87.5 25.0 3.2 83.1 27.5 2.7 78.4 30.3 2.4 73.3 33.4 2.0
7.0
98.8 20.9 4.2 94.7 22.9 3.7 90.3 25.1 3.2 85.7 27.7 2.8 80.9 30.5 2.4 75.7 33.6 2.1
8.0
101.9 21.1 4.3 97.6 23.0 3.8 93.2 25.3 3.3 88.4 27.8 2.9 83.5 30.7 2.5 78.2 33.8 2.1
9.0
105.1 21.3 4.4 100.7 23.2 3.9 96.0 25.4 3.4 91.2 28.0 3.0 86.2 30.8 2.6 42.5 14.9 2.4
10.0
108.3 21.4 4.5 103.7 23.4 4.0 99.0 25.6 3.5 94.0 28.2 3.0 88.8 31.0 2.6 43.9 14.9 2.5
11.0
111.6 21.6 4.6 106.9 23.5 4.1 102.0 25.8 3.6 96.9 28.3 3.1 91.5 31.2 2.7 45.3 14.9 2.6
12.0
114.9 21.8 4.7 110.1 23.7 4.2 105.0 26.0 3.7 99.8 28.5 3.2 94.3 31.4 2.8 46.7 15.0 2.6
YCUL0036EC
AIR TEMPERATURE ON - CONDENSER (°C)
LCWT
(°C)
25°C 30°C 35°C 40°C 45°C 50°C
KWo KWi COP KWo KWi COP KWo KWi COP KWo KWi COP KWo KWi COP KWo KWi COP
2.0
101.7 24.5 3.7 97.3 27.1 3.3 92.8 30.0 2.8 88.1 33.2 2.4 83.2 36.7 2.1 40.6 18.0 2.0
3.0
105.0 24.7 3.8 100.5 27.3 3.3 95.9 30.3 2.9 91.0 33.5 2.5 86.1 36.9 2.2 42.1 18.0 2.0
4.0
108.4 24.9 3.9 103.8 27.5 3.4 99.0 30.5 3.0 94.1 33.7 2.6 88.9 37.2 2.2 43.5 18.1 2.1
5.0
111.9 25.1 4.0 107.2 27.7 3.5 102.3 30.7 3.1 97.2 33.9 2.7 91.9 37.4 2.3 45.0 18.2 2.1
6.0
115.4 25.3 4.1 110.6 27.9 3.6 105.5 30.9 3.1 100.3 34.1 2.7 94.9 37.7 2.3 46.6 18.3 2.2
7.0
118.9 25.6 4.2 114.1 28.2 3.7 108.9 31.1 3.2 103.5 34.4 2.8 97.9 37.9 2.4 48.1 18.3 2.3
8.0
122.6 25.8 4.3 117.6 28.4 3.8 112.3 31.3 3.3 106.8 34.6 2.9 101.0 38.2 2.5 49.7 18.4 2.3
9.0
126.3 26.0 4.4 121.2 28.6 3.9 115.8 31.6 3.4 110.1 34.9 2.9 104.2 38.5 2.5 51.4 18.5 2.4
10.0
130.1 26.3 4.5 124.8 28.9 3.9 119.3 31.8 3.4 113.5 35.1 3.0 107.4 38.8 2.6 53.0 18.6 2.5
11.0
133.9 26.5 4.6 128.5 29.1 4.0 122.9 32.1 3.5 116.9 35.4 3.1 110.7 39.0 2.7 54.7 18.7 2.6
12.0
137.8 26.8 4.7 132.3 29.4 4.1 126.5 32.4 3.6 120.4 35.7 3.1 114.0 39.3 2.7 56.5 18.8 2.6
