York MA Air Cleaner User Manual



262675-UIM-A-0806
Unitary Products Group 11
* May be 0 (no breaker) or 1 (with breaker).
TABLE 13:
Electrical Data - (For
Single Source
Power Supply) - Copper Wire 1 Ø - 208/230-1-60
Models
MA
Heat Kit - Single
Phase*
Heater
Amps
240V
Field Wiring
Min. Circuit Ampacity
Max. O.C.P.
1
Amps/Type
75°C Wire Size - AWG
208V 240V 208V 240V 208V 240V
08BN21
4HK*6500206 10.4 13.03 14.88 15 15 14 14
4HK*6500506 20.0 23.42 26.88 30 30 10 10
4HK*6500806 31.3 35.60 41.00 40 45 8 8
4HK*6501006 40.0 45.08 51.88 50 60 8 6
12BN21
4HK*6500506 20.0 25.79 29.38 30 30 10 10
4HK*6500806 31.3 37.98 43.50 40 45 8 8
4HK*6501006 40.0 47.46 54.38 50 60 8 6
4HK165N1506 60.0 69.13 79.38 70 90 4 3
14DN21
4HK*6500506 20.0 24.29 28.00 30 30 8 10
4HK*6500806 31.3 36.48 42.13 40 45 8 8
4HK*6501006 40.0 45.96 53.00 50 60 8 6
4HK16501506 60.0 67.63 78.00 70 90 4 3
4HK16501806 73.3 82.07 94.63 90 100 4 3
4HK16502006 80.0 89.29 103.00 100 110 3 2
16CN21
4HK*6500506 20.0 26.17 30.00 30 30 8 8
4HK*6500806 31.3 38.35 44.13 40 45 8 8
4HK*6501006 40.0 47.83 55.00 50 60 8 6
4HK16501506 60.0 69.50 80.00 70 90 4 3
4HK16501806 73.3 83.94 96.63 90 100 4 3
4HK16502006 80.0 91.17 105.00 100 110 3 2
20DN21
4HK*6500806 31.3 42.60 48.38 45 50 8 8
4HK*6501006 40.0 52.08 59.25 60 60 8 6
4HK16501506 60.0 73.75 84.25 90 90 3 3
4HK16501806 73.3 88.19 100.88 90 110 3 2
4HK16502006 80.0 95.42 109.25 100 125 3 2
4HK16502506 100.0 117.08 134.25 125 150 1 1/0
1. O.C.P. = Over Current Protection device, must be HACR type Circuit Breaker or Time Delay fuse.
TABLE 14:
Electrical Data - 3 Ø - 208/230-3-60
Models
MA
Heat Kit -
Three Phase
Max.
Static
Min.
Speed
Tap
Total Heat
1
KW Staging
KW MBH W1 Only W2 Only W1 + W2
208V 240V 208V 240V 208V 240V 208V 240V 208V 240V
08B 4HK06501025 0.5 Hi 7.2 9.6 24.6 32.8 7.2 9.6 7.2 9.6 7.2 9.6
12B 4HK06501025 0.5 Med 7.2 9.6 24.6 32.8 7.2 9.6 7.2 9.6 7.2 9.6
14D
4HK06501025 0.5 Med 7.2 9.6 24.6 32.8 7.2 9.6 7.2 9.6 7.2 9.6
4HK06501525 0.5 Med 10.8 14.4 36.9 49.1 10.8 14.4 10.8 14.4 10.8 14.4
4HK06501825 0.5 Hi 12.9 17.2 44.7 58.7 12.9 17.2 12.9 17.2 12.9 17.2
16C
4HK06501025 0.5 Med 7.2 9.6 24.6 32.8 7.2 9.6 7.2 9.6 7.2 9.6
4HK06501525 0.5 Med 10.8 14.4 36.9 49.1 10.8 14.4 10.8 14.4 10.8 14.4
4HK06501825 0.5 Hi 12.9 17.2 44.7 58.7 12.9 17.2 12.9 17.2 12.9 17.2
20D
4HK06501025 0.5 Lo 7.2 9.6 24.6 32.8 7.2 9.6 7.2 9.6 7.2 9.6
4HK06501525 0.5 Med 10.8 14.4 36.9 49.1 10.8 14.4 10.8 14.4 10.8 14.4
4HK16502525 0.5 Med 18.0 24.0 61.4 81.4 9.0 12.0 18.0 24.0 18.0 24.0
1. See conversion Table 10.
