Multipliers for determining the performance with other indoor sections.
NOTE: For dry bulb temperatures different than those listed (between 73-87 F), sensible capacity increases by 1060 BTUH per 1000 CFM per degree above the
listed temperature and decreases by 1060 BTUH per 1000 CFM per degree below the listed temperature.
* = Single-phase outdoor units only.
* = Single-phase outdoor units only.
COOLING PERFORMANCE DATA
AIR CONDITIONER MODEL NO. H2RD060S06, H1RD060S(25,46)**
INDOOR COIL MODEL NO. FC/MC/PC/UC60
CONDENSING
ENTERING AIR
TEMPERATURE
IDCFM 1650 1900 2150
ID DB (°F) 80 80 75 80 80 80 80 75 80 80 80 80 75 80 80
ID WB (°F) 57 62 62 67 72 57 62 62 67 72 57 62 62 67 72
65
T.C. 57.2 57.4 54.0 59.6 59.1 58.9 59.1 55.2 60.4 61.1 60.6 60.8 56.3 61.2 63.1
S.C. 52.1 48.7 39.6 38.8 28.1 54.1 51.9 42.7 42.0 31.1 56.1 55.2 45.7 45.3 34.1
KW 3.0 3.1 3.1 3.1 3.1 3.0 3.1 3.1 3.1 3.1 3.1 3.1 3.1 3.1 3.1
75
T.C. 54.9 55.1 51.6 57.2 57.0 56.9 56.8 52.7 58.1 58.2 59.0 58.5 53.8 59.0 59.5
S.C. 50.0 47.4 38.6 38.0 27.7 52.1 50.5 41.6 41.1 30.0 54.2 53.6 44.7 44.2 32.3
KW 3.5 3.5 3.5 3.6 3.6 3.5 3.5 3.5 3.6 3.6 3.5 3.5 3.5 3.6 3.6
85
T.C. 52.6 52.9 49.3 54.8 54.8 54.9 54.5 50.3 55.8 55.4 57.3 56.1 51.2 56.9 55.9
S.C. 48.0 46.1 37.6 37.3 27.3 50.1 49.0 40.6 40.2 28.8 52.3 52.0 43.6 43.2 30.4
KW 4.0 4.0 4.0 4.0 4.1 4.0 4.0 4.0 4.0 4.1 4.0 4.0 4.0 4.0 4.1
95
T.C. 50.2 50.7 46.9 52.4 52.7 52.9 52.2 47.8 55.0 52.5 55.6 53.7 48.7 54.7 52.3
S.C. 45.9 44.8 36.5 36.5 26.9 48.1 47.6 39.5 39.6 27.7 50.4 50.4 42.5 42.1 28.5
KW 4.4 4.4 4.4 4.4 4.6 4.5 4.4 4.4 4.5 4.6 4.5 4.4 4.4 4.5 4.6
105
T.C. 48.3 48.2 44.9 49.9 49.4 50.5 49.9 45.3 50.8 49.2 52.8 51.6 45.6 51.6 49.0
S.C. 43.9 43.2 35.6 35.4 25.7 46.0 45.6 38.4 38.1 26.8 48.0 47.9 41.1 40.8 28.0
KW 5.1 5.0 5.1 5.1 5.2 5.1 5.1 5.1 5.1 5.2 5.1 5.1 5.1 5.1 5.2
115
T.C. 46.4 45.9 43.0 47.5 46.1 48.2 47.7 42.8 48.1 46.0 50.0 49.6 42.5 48.6 45.9
S.C. 42.0 41.7 34.7 34.4 24.6 43.9 43.6 37.2 37.0 26.0 45.7 45.5 39.8 39.5 27.5
KW 5.7 5.7 5.7 5.7 5.8 5.7 5.7 5.7 5.7 5.8 5.7 5.7 5.7 5.7 5.8
125
T.C. 44.5 43.5 41.1 45.1 42.9 45.8 45.5 40.3 45.3 42.8 47.2 47.6 39.5 45.6 42.7
S.C. 40.1 40.2 33.7 33.4 23.5 41.8 41.6 36.1 35.8 25.2 43.4 43.1 38.4 38.3 26.9
KW 6.3 6.3 6.3 6.3 6.4 6.3 6.3 6.3 6.3 6.5 6.3 6.4 6.3 6.3 6.5
NOTE: ALL CAPACITIES INCLUDE INDOOR FAN HEAT AT 1250 BTUH/1000 CFM.
** For three-phase, decrease T.C. by 0.5 and S.C. by 0.3.
Air Handler Coil T.C. S.C. KW
MA20D MC60D 1.00 1.00 1.00
MA20D MC61D 1.01 1.01 1.01
MA20D G*FD060H24 1.00 1.00 1.00
MA20D G*FD061H24 1.01 1.01 1.01
AHP/SHP60 – 1.00 1.02 1.00
F*FV060* – 1.00 1.02 1.00
MV20D* FC/MC60D 0.98 0.97 0.98
MV20D* MC61D 1.01 0.99 1.01
AV/SV60* – 1.00 1.02 1.00
– MC61 1.01 1.01 1.01
– HC60 1.00 1.00 1.00
– HD60 1.00 1.01 1.00
– G*FA060S21,24 1.00 1.00 1.00
– G*FD060H24 1.00 1.00 1.00
– G*FD061H24 1.01 1.01 1.01
MA20D MC60D 1.00 1.00 1.00
Variable Speed
Furnace*
Coil T.C. S.C. KW
P(C,V)9*D20 FC/MC/PC60D 0.99 0.96 0.99
PV8*C20 FC/PC60C 0.98 0.98 0.98
P(C,V)9*C20 FC/PC60C 0.99 0.96 0.99
PV8*C20 HC60 0.98 0.98 0.98
P(C,V)9*D20 HC60 0.99 0.96 0.99
PV8*C20 HD60 1.00 0.99 1.00
P(C,V)9*C20 HD60 0.99 0.96 0.99
P(C,V)9*D20 HD60 0.98 0.96 0.98
PV8*C20 MC61D 1.00 0.99 1.00
P(C,V)9*C20 MC61D 0.98 0.96 0.98
P(C,V)9*D20 MC61D 1.00 0.96 1.00
