254892-YTG-C-0606
18 Unitary Products Group
Multipliers for determining the performance with other indoor sections.
NOTE: For dry bulb temperatures different than those listed (between 73-87 F), sensible capacity increases by 1060 BTUH per 1000 CFM per degree above the
listed temperature and decreases by 1060 BTUH per 1000 CFM per degree below the listed temperature.
COOLING PERFORMANCE DATA
AIR CONDITIONER MODEL NO. H2RD024S06
INDOOR COIL MODEL NO. FC/MC/PC/UC24
CONDENSING
ENTERING AIR
TEMPERATURE
IDCFM 600 800 1000
ID DB (°F) 80 80 75 80 80 80 80 75 80 80 80 80 75 80 80
ID WB (°F) 57 62 62 67 72 57 62 62 67 72 57 62 62 67 72
75
T.C. 21.8 23.8 23.8 25.7 28.3 24.1 25.1 25.1 26.8 29.8 21.8 26.5 26.5 28.0 31.3
S.C. 21.8 19.5 15.2 16.6 13.6 24.1 23.0 17.6 19.1 15.6 20.4 26.4 19.9 21.6 17.5
KW 1.60 1.62 1.62 1.65 1.67 1.70 1.71 1.71 1.73 1.75 1.60 1.79 1.79 1.81 1.84
85
T.C. 20.4 21.9 21.9 24.2 26.4 21.4 23.6 23.6 25.3 27.7 22.5 25.3 25.3 26.3 29.0
S.C. 20.4 18.6 14.2 16.1 13.0 21.4 21.8 16.4 18.7 14.9 22.1 25.0 18.5 21.3 16.8
KW 1.71 1.72 1.72 1.77 1.79 1.77 1.82 1.82 1.85 1.88 1.83 1.91 1.91 1.94 1.97
95
T.C. 19.0 20.0 20.0 22.7 24.5 21.6 22.1 22.1 23.8 25.7 23.2 24.1 24.1 24.7 26.8
S.C. 18.7 17.6 13.3 15.5 12.3 21.2 20.6 15.2 16.6 14.2 23.2 23.6 17.1 21.0 16.0
KW 1.81 1.82 1.82 1.88 1.92 1.93 1.93 1.93 1.98 2.01 2.05 2.04 2.04 2.06 2.11
105
T.C. 17.6 18.1 18.1 21.2 22.6 20.8 20.5 20.5 22.1 23.6 23.9 22.9 22.9 23.1 24.6
S.C. 17.6 16.7 12.3 15.0 11.7 20.3 19.4 14.0 17.8 13.5 23.9 22.2 15.7 20.7 15.3
KW 1.92 1.92 1.92 2.00 2.04 2.09 2.04 2.04 2.09 2.14 2.27 2.16 2.16 2.19 2.25
115
T.C. 19.3 17.0 17.0 19.3 21.1 20.3 18.8 18.8 20.2 22.0 21.2 20.7 20.7 21.1 22.9
S.C. 19.316.011.714.211.220.318.212.816.813.121.220.514.019.414.9
KW 2.10 2.01 2.01 2.10 2.16 2.21 2.14 2.14 2.20 2.26 2.32 2.28 2.28 2.30 2.37
125
T.C. 15.4 15.8 15.8 17.4 19.6 17.0 17.2 17.2 18.3 20.4 18.5 18.5 18.5 19.2 21.2
S.C. 15.4 15.4 11.1 13.5 10.7 17.0 17.1 11.7 15.8 12.7 18.5 18.5 12.2 18.0 14.6
KW 2.09 2.09 2.09 2.19 2.28 2.24 2.24 2.24 2.30 2.39 2.37 2.39 2.39 2.41 2.49
NOTE: ALL CAPACITIES INCLUDE INDOOR FAN HEAT AT 1250 BTUH/1000 CFM.
Air Handler Coil T.C. S.C. KW
MA08B MC24B 1.00 1.00 1.00
MA08B MC30B 1.00 1.00 1.00
MA08B G*FD024H17 1.00 1.00 1.00
MA08B G*FD030H17 1.00 1.00 1.00
AHP24 – 1.02 1.01 1.00
AHP30 – 1.02 1.02 1.03
F*FP024 – 1.02 1.01 1.00
F*FP030 – 1.02 1.01 1.00
MV12B FC/MC24B 1.02 0.99 0.97
MV12B FC/MC30B 1.02 0.99 0.97
AV24 – 1.02 0.99 0.97
– FC/MC/PC/UC30 1.00 1.00 1.00
– HC30 1.02 1.02 1.02
– HD24 1.03 1.04 1.02
– G*FA030S14 1.00 1.00 1.00
– G*FA036S14 1.00 1.00 1.00
– G*FA036S17,21 1.00 1.00 1.00
– G*FD024H14,17 1.00 1.00 1.00
– G*FD030H17 1.00 1.00 1.00
– G*FD035H14 1.00 1.00 1.00
– G*FD036H17 1.00 1.00 1.00
Variable Speed
Furnace
Coil T.C. S.C. KW
PV8*A12 FC/MC/PC24A 1.01 1.01 0.96
PV9*A12 FC/MC/PC/24A 1.01 1.01 0.97
PV8*B16 FC/MC/PC/24B 1.01 1.01 0.96
P(C,V)9*B12 FC/MC/PC24B 1.01 1.01 0.96
PV8*A12 FC/MC/PC30A 1.01 1.01 0.96
PV9*A12 FC/MC/PC30A 1.01 1.01 0.97
PV8*B16 FC/MC/PC30B 1.01 1.01 0.96
P(C,V)9*B12 FC/MC/PC30B 1.01 1.01 0.96
PV8*A12 HC30 1.02 1.03 0.98
PV9*A12 HC30 1.02 1.02 0.98
PV8*A12 HD24 1.04 1.04 0.99
PV9*A12 HD24 1.04 1.04 0.99
