272442-UUM-B-1211
10 Unitary Products Group
FIELD INSTALLED ACCESSORIES - NON-ELECTRICAL
ITEM DESCRIPTION
MOTOR
1 MOTOR, BELT DRIVEN BLOWER
2 MOTOR, VENTOR ASS’Y
ELECTRICAL
3 CONTROL, HIGH LIMIT (2 Req’d)
4 CONTROL, FURNACE [FC]
5IGNITER
6 SENSOR, FLAME
7 SWITCH, AIR PRESSURE [1LP]
8 SWITCH, DOOR
9 TRANSFORMER
10 CONTACTOR
11 VALVE, GAS
12
SWITCH, FLAME ROLL-OUT (2 Req’d, [ROS3,4])
13
CONTROL,FLAME ROLL OUT (2 Req’d,[ROS1,2])
13A FUSE
14 RELAY, TIME DELAY
AIR MOVING
15 HOUSING, BLOWER
16 WHEEL, BLOWER
17 CUTOFF, BLOWER
18 SHAFT, BLOWER
19 PULLEY, FIXED (Blower Wheel)
20 SPACER
21 BEARING, BALL (2 Req’d)
22 BELT, BLOWER
23 PULLEY, VARIABLE (Motor)
23A SPIDER, BLOWER
FABRICATED PARTS
24 SHIELD, SECONDARY AIR
25 BAFFLE, FLUE
26 BURNER, MAIN GAS
27 BRACKET, IGNITER
28 DECK, BLOWER (Rear)
28A PANEL, BLOWER MOUNTING
29 HEAT EXCHANGER ASS’Y (Primary)
30 MANIFOLD, GAS
31 PANEL, UPPER ACCESS
32 PANEL, BASE
33 PANEL, BLOWER ACCESS
34 PANEL, TOP
35 WRAPPER, REAR
36 WRAPPER, CABINET (LH)
37 WRAPPER, CABINET (RH)
38 CHANNEL, TOE PLATE
39 PLUG, WINDOW, CLEAR - .875”
40 BRACKET, ROLL-OUT SWITCH
41 SHIELD, HEAT
41A BEZE;/LOGO ASSEMBLY
MISCELLANEOUS
42 ORIFICE, BURNER (Natural #43)
43 PLATE, RESTRICTOR
44 COLLAR, FLUE
45 HANDLE, DOOR
46 GASKET, RESTRICTOR PLATE
47 TUBING, RUBBER
48 SPRING, DOOR (2 Req’d)
49 BRACKET, MOUNT MOTOR
50 DIAGRAM, WIRING
51 COLLAR SHAFT
52 S27 KEYSTOCK 1-1/4” LG.
53 SHIELD, INDUCER
54 HARNESS, MAIN WIRING
ITEM DESCRIPTION
NOTE: *Not Shown
Major components and suggested stocking items are shown with shaded item number.
MODEL NO. DESCRIPTION
1NP0349 PROPANE (LP) CONVERSION KIT
1BR0432 FILTER FRAME KIT, BOTTOM
1SR0402 FILTER FRAME KIT, SIDE
1PS0301 HIGH ALTITUDE PRESSURE SWITCH
REPLACEMENT PART CONTACT INFORMATION
This is a generic parts list. To request a complete parts list, refer to the contact information below:
• Visit our website at www.source1parts.com for the following information:
1. Search for a part or browse the catalog.
2. Find a dealer or distributor.
3. Customer Service contact information.
a. Click on the “Brand Links” button
b. Click on the “Customer Service” button
• You can contact us by mail. Just send a written request to:
York International
Consumer Relations
5005 York Drive
Norman, OK 73069
