262260-YTG-E-1008
Johnson Controls Unitary Products 29
NOTE 1: HACR Type per NEC.
NOTE 1: HACR Type per NEC.
TABLE 20: DH 300 ELECTRICAL DATA STANDARD MOTOR WITHOUT POWERED CONVENIENCE OUTLET
MODEL
(TON-
NAGE)
VOLTAGE
COMPRESSORS
OD FAN
MOTORS
FLA EACH
ID
BLOWER
MOTOR
FLA
CONV
OUTLET
AMPS
HEATER OPTION
MIN.
CIRCUIT
AMPACITY
(AMPS)
MAX.
FUSE/
BRKR
1
SIZE
(AMPS)
RLA
EACH
LRA
EACH
MODEL KW STAGES AMPS
300
(25)
208 37.1 239 4.5 28.0 0.0
None - - - 120.5 150
E18 13.5 1 37.5 120.5 150
E36 27.0 2 74.9 128.7 150
E54 40.6 2 112.7 175.9 200
E72 54.1 2 150.2 185.2 200
230 37.1 239 4.3 26.0 0.0
None - - - 118.1 150
E18 18.0 1 43.3 118.1 150
E36 36.0 2 86.6 140.8 150
E54 54.0 2 129.9 162.4 175
E72 72.0 2 173.2 205.7 225
460 17.2 125 2.2 13.0 0.0
None - - - 56.1 70
E18 18.0 1 21.7 56.1 70
E36 36.0 2 43.3 70.4 80
E54 54.0 2 65.0 81.2 90
E72 72.0 2 86.6 102.9 110
575 12.4 80 1.7 10.0 0.0
None - - - 41.3 50
E18 18.0 1 17.3 41.3 50
E36 36.0 2 34.6 55.8 60
E54 54.0 2 52.0 64.5 70
E72 72.0 2 69.3 81.8 90
TABLE 21: DH 300 ELECTRICAL DATA HIGH STATIC MOTOR WITHOUT POWERED CONVENIENCE OUTLET
MODEL
(TON-
NAGE)
VOLTAGE
COMPRESSORS
OD FAN
MOTORS
FLA EACH
ID
BLOWER
MOTOR
FLA
CONV
OUTLET
AMPS
HEATER OPTION
MIN.
CIRCUIT
AMPACITY
(AMPS)
MAX.
FUSE/
BRKR
1
SIZE
(AMPS)
RLA
EACH
LRA
EACH
MODEL KW STAGES AMPS
300
(25)
208 37.1 239 4.5 38.6 0.0
None - - - 131.5 150
E18 13.5 1 37.5 131.5 150
E36 27.0 2 74.9 141.9 150
E54 40.6 2 112.7 189.1 200
E72 54.1 2 150.2 198.4 225
230 37.1 239 4.3 38.6 0.0
None - - - 131.1 150
E18 18.0 1 43.3 131.1 150
E36 36.0 2 86.6 156.5 175
E54 54.0 2 129.9 178.2 200
E72 72.0 2 173.2 221.5 250
460 17.2 125 2.2 19.3 0.0
None - - - 62.9 80
E18 18.0 1 21.7 62.9 80
E36 36.0 2 43.3 78.3 80
E54 54.0 2 65.0 89.1 100
E72 72.0 2 86.6 110.7 125
575 12.4 80 1.7 15.4 0.0
None - - - 47.5 60
E18 18.0 1 17.3 47.5 60
E36 36.0 2 34.6 62.6 70
E54 54.0 2 52.0 71.2 80
E72 72.0 2 69.3 88.5 100
