TABLE 5: DH 210 COOLING CAPACITIES (17.5 TON)
AIR ON
EVAPORATOR
COIL
TEMPERATURE OF AIR ON CONDENSER COIL
75°F 85°F
TOTAL
CAP.
1
MBH
POWER
INPUT
2
KW
SENSIBLE CAPACITY, MBH
TOTAL
CAP.
1
MBH
POWER
INPUT
2
KW
SENSIBLE CAPACITY, MBH
ENTERING DRY BULB, °F ENTERING DRY BULB, °F
CFM
WB
°F
90 85 80 75 70 65 90 85 80 75 70 65
5250
77 241.5 13.9 119.5 94.6 69.6 - - - 240.2 15.6 119.7 94.8 69.9 - - -
72 232.2 13.2 159.7 134.8 109.8 84.9 - - 226.1 15.1 156.3 131.4 106.4 81.5 - -
67 223.0 12.6 199.9 174.9 150.0 125.1 100.1 - 212.0 14.5 192.9 167.9 143.0 118.1 93.1 -
62 204.4 12.4 204.4 204.4 182.1 157.1 132.2 107.2 193.5 14.3 193.5 193.5 170.5 145.5 120.6 95.6
57 200.4 12.6 200.4 200.4 183.1 158.2 133.2 108.3 191.2 14.3 191.2 191.2 171.8 146.9 121.9 97.0
6125
77 250.1 14.5 136.3 104.8 75.3 - - - 248.8 16.0 140.3 105.8 76.3 - - -
72 240.5 13.8 177.8 148.3 118.9 89.4 - - 234.2 15.4 175.2 145.7 116.2 86.7 - -
67 231.0 13.1 219.4 191.9 162.4 132.9 103.4 - 219.6 14.9 210.0 185.6 156.2 126.7 97.2 -
62 211.7 12.9 211.7 211.7 197.2 167.7 138.2 108.7 200.5 14.7 200.5 200.5 186.1 156.6 127.2 97.7
57 207.6 13.1 207.6 207.6 198.3 168.8 139.3 109.9 198.0 14.7 198.0 198.0 187.6 158.1 128.6 99.1
7000
77 258.7 15.1 153.0 115.0 81.0 - - - 257.4 16.4 160.9 116.7 82.7 - - -
72 248.8 14.4 195.9 161.9 127.9 93.9 - - 242.3 15.8 194.0 160.0 126.0 92.0 - -
67 238.9 13.7 238.9 208.8 174.8 140.8 106.8 - 227.2 15.2 227.2 203.3 169.3 135.3 101.3 -
62 219.0 13.5 219.0 219.0 212.3 178.3 144.3 110.2 207.4 15.0 207.4 207.4 201.8 167.8 133.8 99.7
57 214.7 13.7 214.7 214.7 213.5 179.5 145.5 111.4 204.9 15.0 204.9 204.9 203.4 169.4 135.4 101.3
7875
72 253.0 14.5 214.9 176.1 137.4 98.6 - - 246.9 15.9 212.6 173.9 135.2 96.4 - -
67 243.0 13.8 243.0 227.9 187.8 149.0 110.3 - 231.6 15.3 231.6 219.6 181.6 142.9 104.1 -
62 222.7 13.6 222.7 222.7 219.4 180.6 141.9 103.1 211.4 15.1 211.4 211.4 208.6 169.8 131.1 92.3
57 218.3 13.8 218.3 218.3 217.7 179.0 140.2 101.5 208.8 15.1 208.8 208.8 208.1 169.3 130.6 91.8
8750
72 257.2 14.6 233.8 190.3 146.9 103.4 - - 251.6 16.0 231.2 187.8 144.3 100.8 - -
67 247.0 13.9 247.0 247.0 200.7 157.2 113.8 - 235.9 15.4 235.9 235.9 193.9 150.4 107.0 -
62 226.4 13.7 226.4 226.4 226.4 183.0 139.5 96.0 215.3 15.2 215.3 215.3 215.3 171.9 128.4 84.9
57 222.0 13.9 222.0 222.0 222.0 178.5 135.0 91.6 212.7 15.2 212.7 212.7 212.7 169.3 125.8 82.3
AIR ON
EVAPORATOR
COIL
TEMPERATURE OF AIR ON CONDENSER COIL
95°F 105°F
TOTAL
CAP.
1
MBH
POWER
INPUT
2
KW
SENSIBLE CAPACITY, MBH
TOTAL
CAP.
1
MBH
POWER
INPUT
2
KW
SENSIBLE CAPACITY, MBH
ENTERING DRY BULB, °F ENTERING DRY BULB, °F
CFM
WB
°F
90 85 80 75 70 65 90 85 80 75 70 65
5250
77 238.9 17.4 120.0 95.0 70.1 - - - 228.3 15.0 116.1 91.2 66.2 - - -
72 219.9 16.9 152.9 128.0 103.0 78.1 - - 209.9 14.6 148.0 123.0 98.1 73.1 - -
67 201.0 16.5 185.9 160.9 136.0 111.1 86.1 - 191.5 14.2 179.8 154.8 129.9 105.0 80.0 -
62 182.6 16.3 182.6 182.6 158.8 133.9 108.9 84.0 176.2 14.0 176.2 176.2 152.7 127.8 102.9 77.9
57 182.0 16.1 182.0 182.0 160.5 135.5 110.6 85.6 176.4 13.9 176.4 176.4 153.3 128.3 103.4 78.4
6125
77 247.5 17.6 144.4 106.7 77.2 - - - 235.7 17.2 143.3 102.8 73.3 - - -
72 235.0 17.2 172.5 143.1 124.0 84.1 - - 223.4 19.0 167.5 138.0 108.6 79.1 - -
67 215.5 16.7 200.7 179.4 163.8 120.4 90.9 - 203.8 18.5 191.8 173.3 143.8 114.3 84.8 -
62 195.8 16.5 189.2 189.2 191.3 145.6 116.1 86.6 187.4 18.2 181.8 181.8 169.1 139.6 110.1 80.6
57 195.1 16.3 188.5 188.5 193.3 147.4 117.9 88.4 187.8 18.1 182.1 182.1 169.7 140.2 110.7 81.2
7000
77 256.1 17.7 168.8 118.4 84.4 - - - 243.0 19.5 170.4 114.4 80.4 - - -
72 235.8 17.2 192.1 158.1 124.1 90.1 - - 223.4 19.0 187.1 153.1 119.1 85.0 - -
67 215.5 16.7 215.5 197.8 163.8 129.8 95.8 - 203.8 18.5 203.8 191.7 157.7 123.7 89.7 -
62 195.8 16.5 195.8 195.8 191.3 157.3 123.3 89.2 187.5 18.2 187.5 187.5 185.5 151.4 117.4 83.4
57 195.1 16.3 195.1 195.1 193.3 159.3 125.3 91.2 187.8 18.1 187.8 187.8 186.1 152.0 118.0 84.0
7875
72 240.9 17.3 210.4 171.7 132.9 94.2 - - 228.3 19.1 205.3 166.5 127.8 89.0 - -
67 220.2 16.8 220.2 211.3 175.5 136.7 98.0 - 208.3 18.6 208.3 202.2 169.3 130.5 91.8 -
62 200.0 16.6 200.0 200.0 197.8 159.0 120.3 81.5 191.6 18.3 191.6 191.6 190.6 151.8 113.1 74.3
57 199.3 16.4 199.3 199.3 198.4 159.7 120.9 82.2 191.9 18.2 191.9 191.9 191.0 152.3 113.5 74.8
8750
72 246.0 17.4 228.7 185.2 141.8 98.3 - - 233.2 19.2 223.5 180.0 136.5 93.1 - -
67 224.8 16.9 224.8 224.8 187.1 143.6 100.2 - 212.8 18.7 212.8 212.8 180.9 137.4 93.9 -
62 204.2 16.7 204.2 204.2 204.2 160.8 117.3 73.8 195.7 18.4 195.7 195.7 195.7 152.2 108.7 65.3
57 203.5 16.5 203.5 203.5 203.5 160.0 116.6 73.1 196.0 18.3 196.0 196.0 196.0 152.5 109.1 65.6
