NOTE: DIAGRAMS & ILLUSTRATION NOT TO SCALE.
10
ACCESSORIES AND COMPONENTS
Blower Kits
-Single Speed 80L84 FBK-100
-Variable Speed 80L85 FBK-200
(FBK-200 Models Only)
Decorative Volcanic Stone 80L42 FDVS
Decorative Volcanic Stone
The decorative volcanic stone, Model FDVS,
can be used to enhance the look of your appli-
ance. Decorative volcanic stone is standard
with this appliance. Order model FDVS for
replacement of stone when needed. Spread the
decorative volcanic stone evenly around the
bottom of the firebox.
Blower Kit
The FBK-100 blower provides for a constant
velocity forced air circulation feature for your
appliance. The FBK-200 assembly with vari-
able speed wall switch provides a forced air
circulation feature for your appliance.
FIREBOX FINISHES
There are a wide variety of “finished looks” for
your built-in unvented firebox from formal wall
decor with elaborate mantels to rustic wood
paneling or warm brick facings.
Only noncombustible materials like marble,
stone, tile, brick, etc. may overlap the black
front facing but be sure not to block the upper
or lower grilles. Seal all joints between the black
facing and wall surrounds to prevent air intru-
sion. Use noncombustible caulking material
only to seal the black metal facing to the sur-
round material on the finished wall.
REPLACEMENT PARTS
An exploded view of the firebox with num-
bered parts and a replacement parts list can be
found on page 11. Normally, all parts should
be ordered through your distributor or dealer.
Parts will be shipped at prevailing prices at
time of order.
When ordering repair parts, always give the
following information:
1. The model number of the firebox.
2. The serial number of the firebox.
3. The part number.
4. The description of the part.
5. The quantity required.
6. The installation date of the firebox.
If you encounter any problems or have any
questions concerning the installation of a un-
vented heater in this system, please contact
your distributor or dealer.
