ENGLISH
E-3
Weight table (Unit: kg)
Accessories packaged with the TV
*The screw notation M6 means the diameter of the threaded part is 6 mm.
*Please also store the screws that are not used.
Base bracket: 1 Wall-mount bracket: 1
*Assembly completed
for perpendicular
installation.
M6 length:
8mm (2 screws)
M8 length:
15mm (2 screws)
• Wall installation screws (off-the-shelf) 17
Be sure to consult the dealership or a qualified contractor when installing the TV.
• Stand hole covers × 2 (Included with the LCD color TV)
• A plumb bob made by tying a coin with a hole in it to the end of a string.
• A pin, such as a thumbtack
• Cushion, soft cloth, etc.
• Tool (Phillips head screwdriver)
• LCD color TVs have a viewing angle (range in which the image can be viewed correctly). The
best viewing position is from directly in front of the screen. Determine the TV installation location
after taking into consideration the viewing posture, line of sight, and the visual and aural ranges.
• Sharp shall bear no responsibility for damages, etc., caused by the LCD color TV falling due
to insufficient installation strength or improper installation.
Please use the following
Installation location
Caution
Screws
M10 length:
30mm (4 screws) with
hexagonal sockets
Operation manual
(This manual)
Angle setup bracket: 2
Allen wrench: 1
For the angle setup
bracket
For fastening the
wall-mount bracket
For installing the wall-
mount bracket unit
