Rinnai RCE-229A Gas Heater User Manual



Model RCE-229A 800-621-941925
PARTS LIST
PART NAME PART No. QTY. REMARKS
121-1 COMBUSTION CHAMBER ASS'Y
RC-219-30
1
121-2 SCREW
ZFAB0408SZ
2
121-3 SCREW
ZFAB0408SC
2
TC SPACER
RC-209-68-1
1 NG, LPG
TC SPACER
RC-209-68-2
1 LPG
123-1 THERMOCOUPLE BRACKET
RC-152-224
1
123-2 SCREW
CP-30523-2
2
124 THERMOCOUPLE TOTAL ASS'Y
RC-511-66-1
1
125-1 THERMOCOUPLE FIXER
RC-210-89-2
1
125-2 SCREW
ZFAB0406SZ
1
126 CONVECTION FAN
RC-229-13
1
128-1 BEARING
RC-223-74
1
128-2 SCREW
ZFAB0406SZ
2
131 CLAMP
CP-90312
1
132 NYLON TACK
RC-215-24-1
1
134-1 SUB P.C.B. BRACKET
RC-229-1013
1
134-2 SCREW
ZFAB040BSZ
1
135-1 POWER SUPPLY CABLE BRACKET
RC-329-1033
1
135-2 SCREW
ZFDB0408SB
1
136 VALVE COVER
RC-606-96
1
137-1 CONNECTION PIPE FIXER
RC-208-21
1
137-2 SCREW
ZFAB0408SZ
1
138-1 OVER HEAT SWITCH
ES-01183
1
138-2 SCREW
CP-30518-1
2
139 CIRCUIT BOARD SPACER
CP-90436-3
4
140-1 OUTLET
RC-229-511
1
140-2 SCREW
ZHAA0412SZ
2
141 CABLE CLIP
CP-90125-2
2
142-1 THERMISTOR HOLDER
RC-229-540
1
142-2 SCREW
ZFAB0408SB
1
143-1 CONVECTION FAN TOTAL ASS'Y
RC-229-523
1
143-2 SCREW
ZFAB0408SC
4
143-3 SCREW
ZFAB0408SZ
2
144-1 PLATE HOLDER
RC-229-539
2
144-2 SCREW
ZFDB0410SB
2
P.C.B. ASS'Y
RC-229-514
1
700-1 P.C.B.
ED-247-V1
1
700-2 P.C.B. FIXER
RC-229-513
1
700-3 SCREW
ZGAA0308SZ
4
700-4 SCREW
ZFAB0410SZ
1
700-5 IGNITER ASS'Y
EI-181-1
1
700-6 SCREW
CP-30421-1
1
701-1 SUB P.C.B.
ED-189
1
701-2 CURRENT FUSE
EP-102-13
1
250V 3A
701-3 SCREW
CP-30421-1
1
702 TF HARNESS
RC-229-530
1
703-1 POWER SUPPLY CORD
CP-90466-1
1
703-2
SCREW CP-30421-1
1
123
122
121
135
134
128
125
No.
703
701
700
144
143
142
140
138
137
