ADDITIONAL CUSTOMER OPERATING INFORMATION
INSTALLATION
Check room size and ventilation. Do not
oversize. Improper sizing may cause
nuisance lock outs.
Make certain the heater is connected intoboth
the gas and the electric power.
CONTROL PANEL LAYOUT
TIME/TEMP DISPLAY
Shows either the
temperatures or coded error
messages.
ON TIMER INDICATOR
Indicates that the ON Timer
mode is in operation.
AUTO-OFF INDICATOR
Indicates the thermostat-off
function is activated.
OFF TIMER INDICATOR
Indicates that the OFF
Timer mode is in operation.
INDICATORS
Indicate what information is
currently displayed on the
LED display.
ECONOMY INDICATOR
Indicates that the
Economy mode is in
operation.
COMBUSTION INDICATOR
Indicates that the burner is
alight and the appliance is
heating the room.
FILTER INDICATOR
Indicates that the filter
needs cleaning.
ON/OFF BUTTON
Main switch for turning
ON/OFF.
AUTO-OFF BUTTON
Selects the thermostat-off
function.
FUNCTION LOCK
Locks all controls when
pressed. (Except OFF)
OFF TIMER BUTTON
Selects operating mode
for delay OFF Timer
function.
ON TIMER BUTTON
Selects operating
mode for delay ON Timer
function.
FUNCTION LOCK INDICATOR
Indicates Function lock
is activated.
TIME/TEMP ADJUSTMENT
Increases or decreases the
temperature setting as well as
changing hours or minutes.
