10Re-fit dust canister into cleaner and push to
lock into position. Then re-fit front cover.
Safety cut-out
If the cleaner overheats a motor protection
thermostat will automatically switch the motor
off. If this happens, switch the cleaner off,
unplug from the power supply and leave
the cleaner to cool for at least 30
minutes. Check the airways for blockages,
empty dust canister and clean the filters before
restarting.
Cleaning the filters
To maintain suction the pleated filter
must be shaken clean each time the dust
canister is emptied. Failure to clean the filter
will reduce suction and could damage the
motor if used for a prolonged period. This may
invalidate the guarantee. If the filters become
damaged they must be replaced.
Pleated filter
This must be shaken clean at every
emptying to maintain suction. To thoroughly
clean it wash it regularly.
To remove it from the dust canister lid turn
the filter
1
/
4
turn anti-clockwise. H Wash in
warm water (no detergent) and allow to air dry
before refitting. The spare pleated filter allows
one filter to be washed and dried whilst the
other is in use.
Motor protection filter
I
The motor protection filter Ò is located
underneath the dust canister
1 Remove the dust canister.
2 Lift out the filter and shake over a dustbin.
The filter may also be washed in water (no
detergents) but must be totally dry before re-
fitting.
3 Replace the filter
Exhaust filter
I
The exhaust filter is located below the dust
canister compartment.
1 Remove the front cover.
2 Remove the exhaust filter Ú by pulling
forward at the top and lift it away.
3 Take the filter out of the cage and shake
vigorously over a dustbin. The filter may also
be washed in warm water. Do not use
detergents. The filter must be completely dry
before re-fitting. Allow filters to air dry
naturally.
4 Replace the filter and front cover.
Changing the belt
If the brush bar stops rotating it is likely that
the drive belt has snapped (usually because the
brush has been stalled). A spare belt is
supplied. Replacement belts can also be
obtained from Morphy Richards.
Accessing the floor nozzle
J
1 Disconnect the cleaner from the mains
supply.
2 Put switch to off position.
3 Remove front cover and dust canister.
4 Press the handle release pedal and place
the cleaner face down, in a flat position on a
soft surface (eg carpet).
6
IH
Ò
Ú
