• Never over extend the hose such that the
cleaner is pulled over.
IMPORTANT: Turning the cleaner sideways
helps prevent the cleaner being pulled along by
the stretch hose.
Using & cleaning turbo nozzle
(Certain models only)
Attach the turbo nozzle to the hose end
connector Í for use on upholstery and stairs.
After use your turbo nozzle may become
clogged. Turn over the nozzle and pull away
any hairs or fibres. If they are tightly wound
around the brush carefully snip the fibres with
scissors, being careful not to damage the brush
bar, pull away from the brush bar and dispose.
Emptying
Empty the dust canister regularly even if it
does not look full this will maintain the
performance.
1 Remove the front cover by lifting the cover
release lever ¤E.
2 Lift-up the dust canister release Î and pull
the canister away from the main body.
3 Take the canister to the dustbin.
4 Turn the lid
1
/
4
turn anti-clockwise to unlock,
lift off the lid with pleated filter, Ì put to one
side. F
5 Lift out the central mesh filter Ô from the
dust canister ÓG. Brush clean if
necessary.
6 Empty out the dust canister Ó.
7 Re-fit the central mesh filter.
8 Shake the pleated filter to remove all dust.
9 Re-fit pleated filter with lid into the dust
canister by lining up the two arrows and
turning the lid
1
/
4
turn clockwise to lock.
5
E
F
Ì
Ó
Ï
Î
¤
‹
Ô
G
