Operating the Controls (continued)
Using Your Humidifier
Refill Display Function
For maximum run time both bottles should be
filled. When both bottles are empty the display
alternates the room humidity reading and “F”
(FILL), informing additional water is required.
The SET readout has a range of 25% to 65% and
is adjusted in increments of 5%. Initially
depressing the humidity button will display the
current humidity setting. Each additional press of
the button increases the setting by 5%. A SET
point of 65% operates the humidifier continuously
regardless of the ROOM reading. The humidistat
that senses the readings is located on the power
cord. Insure that this humidistat is free from
obstruction.
Manual Dry Out
At the end of the humidification season or if you do
not plan to run the humidifier for one week or
more, a manual dry out mechanism is provided to
completely dry out the humidifier cabinet.
NOTE: Be sure to position float retainer to the
normal operating mode (lowest position in slot) for
normal humidifier operation.
Below is a diagram of the slot the float retainer is
located in, at the back of the cabinet.
To do this, simply slide the float retainer located at
the back of the humidifier cabinet to the top
position of the slot it is located in. This will hold the
float in an upward position and the fan will run until
you turn the power off.
