17
26.0 POSITIONING OF FIELD REMOVABLE PARTS
WARNING
Failure to position the parts in
accordance with these diagrams
or failure to use only parts specifi-
cally approved with this heater
may result in property damage
or personal injury.
Figure 13
4 off burner
installation
positions
Figure 12
Glass Door Removal:
Remove the four (4)
screws indicated, then
lift door off.
Visual check for cor-
rect pilot flame.
NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE
As our policy is one of continuous improvement and development, we hope therefore you will
understand we must retain the right to amend details and/or specifications without prior notice.
