23
CLEARANCE TO COMBUSTIBLES
The following clearances meet the minimum requirements for a safe
installation;
Side wall: 18” (457 mm)
Ceiling: 7 feet (2135 mm) measured from the base of the fireplace
Fireplace enclosure:
Bottom: 0”
Side: 0” to spacer
Back: 0” to spacer
Top: Do not fill the space above the fireplace with any material,
7 feet measured from the base of the fireplace (Except the
wood framing). See Page 11, Figure 9.
Chimney: 2” (50 mm)
Mantel: 48” (1219 mm) measured from the base of the fireplace.
Fireplace
Cat. No. Model Description
H7703 SOLANA-BK Solana (w/Black Doors)
H7704 SOLANA-BN Solana (w/Brushed Nickel Doors)
Specifications
Weight 343 lbs
Height 42”
Width 43”
Depth 26-5/8”
Chimney Weight ASHT+ (8” dia) 8.75 lb/ft.
Chimney Weight S-2100+ (8” dia.) 13.2 lb/ft.
Chimney Weight AC (8” dia.) 3.75 lb/ft.
