Cleaner description
10
25
17
18
9
1. Soft touch handle grip
2. ON/OFF switch
3. Telescoping handle
4. Handle adjustment
button
5. Carrying handle
6. Dirt cup release button
7. Dirt cup assembly
8. Cord reel window
9. Headlight
10. Agitator brush roll
shut-off indicator
11. Agitator brush roll
shut-off pedal
12. Furniture guard: helps
prevent cleaner from mark-
ing furniture.
13. Nozzle control knob:
turn knob to correct setting
for height or carpet being
cleaned.
14. Final filter access
15. Hose handle
16. Hose
17. Hose/tool holder
18. Crevice tool
19. Wands
20. Cord reel
21. Soft touch wheels
22. Handle release pedal:
step on lever to lower handle
to operating or low positions.
23. Cord rewind button: press
button to rewind cord for stor-
age. Hold plug until cord is
rewound.
24.Combination tool
25. Powered hand tool
Operate cleaner only at
voltage specified on data
plate on back of cleaner.
This cleaner is intended for
household use.
Polarized plug
To reduce the risk of electric shock,
this appliance has a polarized plug
(one blade is wider than the other),
This plug will fit in a polarized outlet
only one way, If the plug does not fit
fully in the outlet, reverse the plug, If
it still does not fit, contact a qualified
electrician to install the proper out-
let, Do not change the plug in any
way,
m
ON-OFF switch
Plug cord into electrical outlet,
To turn cleaner ON, push ON/OFF
switch once,
To turn cleaner OFF, push switch
again,
The cleaner is shipped with the agi-
tator brush roll in the OFF position,
To turn the agitator brush roll ON,
step on the pedal (A), The indicator
(B) will show red in the "brush roll
on" window,
Continued -_ 5
