SKU 65322 or 65323 For technical questions, please call 1-800-444-3353. Page 24
CRANKSHAFT, PISTON AND CONNECTING ROD
ASSEMBLY DIAGRAM
Part # Description QTY
1d Piston Ring (I) 1
2d Piston Ring (II) 1
3d Side Rail 2
4d Expander 1
5d Scraper Ring Set 1
6d Piston Ring Assembly 1
7d Piston Pin Circlip 2
8d Piston 1
9d Piston Pin 1
Part # Description QTY
10d Connecting Rod 1
11d Connecting Rod Cover 1
12d Bolt 2
13d Connecting Rod Assembly 1
14d Woodruff Key 1
15d Drive Gear 1
16d Crankshaft 1
17d Timing Drive Gear 1
18d Crankshaft Assembly 1
Note: When ordering parts from this list, specify: Parts List D, CRANKSHAFT, PISTON
AND CONNECTING ROD ASSEMBLY, and the Item Number from the table below.
