ProdUCt sPeCiFiCations
ProdUCt sPeCiFiCations
SS-CPG36-72 www.goodmanmfg.com 15
airFlow data — CPG060B (Cont.)
standard Belt drive — horizontal
ESP

2


0 1 2 3 4 5
 BHP  BHP  BHP  BHP  BHP  BHP
0.2 2460 0.96 2251 0.80 2073 0.65 1862 0.51
0.4 2408 1.00 2206 0.84 1982 0.68 1808 0.55 1572 0.41
0.6 2402 1.08 2173 0.89 1943 0.72 1701 0.55 1511 0.43
0.8 2153 0.95 1917 0.77 1667 0.59
1.0 1888 0.82 1634 0.63
1.2 1601 0.67
hiGh-statiC Belt drive — horizontal
ESP

2


0 1 2 3 4 5
 BHP  BHP  BHP  BHP  BHP  BHP
0.6 2219 0.95 1970 0.75
0.8 2215 1.04 1956 0.82 1697 0.62
1.0 2240 1.15 1957 0.90 1681 0.67
1.2 2260 1.26 1983 1.00 1683 0.74
1.4 2288 1.38 2009 1.10 1711 0.84
1.6 2032 1.21 1741 0.93
1.8 1776 1.04
standard Belt drive — down shot
ESP

2


0 1 2 3 4 5
 BHP  BHP  BHP  BHP  BHP  BHP
0.2 2210 0.91 2041 0.76 1869 0.63 1739 0.52 1565 0.40
0.4 2197 0.98 2021 0.82 1841 0.67 1660 0.54 1521 0.44 1339 0.32
0.6 2002 0.88 1822 0.72 1635 0.58 1445 0.44 1288 0.35
0.8 1799 0.77 1610 0.62 1425 0.48
1.0 1587 0.67 1384 0.51
hiGh-statiC Belt drive — down shot
ESP

2


0 1 2 3 4 5
 BHP  BHP  BHP  BHP  BHP  BHP
0.6 2262 1.16 2051 0.95 1851 0.76 1657 0.60
0.8 2277 1.27 2070 1.05 1852 0.84 1646 0.66
1.0 2304 1.39 2089 1.15 1872 0.93 1647 0.72
1.2 2104 1.26 1893 1.03 1668 0.81
1.4 1912 1.13 1690 0.90
1.6 1720 1.00
Note: Tablesrepresentdrycoilwithoutlter;tocompensateforlter,add0.08”tomeasuredE.S.P.SCFMcorrectionforwetcoil=4%.
