PRODUCT DESIGN
HKR ELECTRICAL DATA
All wires and overcurrent protection devices are sized for use with electric heaters only and without
refrigeration. If heaters are not installed with above wire size, overheating and fire could occur. See
PACKAGE COOLING SPECIFICATIONS section for minimum circuit ampacity and maximum overcurrent
protection during refrigeration cycle.
IMPORTANT NOTE: A separate power supply is required for the HKR heater kit.
WARNING
WARNING
GPC15[24-48]M41*
Maximum Maximum
Overcurrent Overcurrent
Protection (amps) Protection (amps)
at 208 / 240V at 208 / 240V
GPC1524M41*
HKR05A,CA
24 / 27 30 / 30 ---- ---- 4.75 / 16,200
HKR08A,CA
33 / 28 40 / 40 ---- ---- 7.00 / 23,800
HKR10A,CA 45 / 51 60 / 60 ---- ---- 9.50 / 32,400
GPC1530M41*
HKR05A,CA 24 / 27 30 / 30 -- -- 4.75 / 16,200
HKR08A,CA 34 / 39 40 / 40 -- -- 7.0 / 23,800
HKR10A,CA 45 / 52 60 / 60 -- -- 9.5 / 32,400
HKR15A,CA 45 / 52 60 / 60 22 / 25 30 / 30 14.25 / 48,600
GPC1536M41*
HKR05A,CA
24 / 27 30 / 30 ---- ---- 4.75 / 16,200
HKR08A,CA
34 / 39 40 / 40 ---- ---- 7.00 / 23,800
HKR10A,CA
45 / 52 60 / 60 ---- ---- 9.50 / 32,400
HKR15A,CA 45 / 52 60 / 60 22 / 25 30 / 30 14.25 / 48,600
GPC1542M41*
HKR05A,CA 24 / 27 30 / 30 -- -- 4.75 / 16,200
HKR08A,CA 34 / 39 40 / 40 -- -- 7.0 / 23,800
HKR10A,CA 45 / 52 60 / 60 -- -- 9.5 / 32,400
HKR15A,CA 45 / 52 60 / 60 22 / 25 30 / 30 14.25 / 48,600
GPC1548M41*
HKR05A,CA
25 / 28 30 / 30 ---- ---- 4.75 / 16,200
HKR08A,CA
34 / 40 40 / 40 ---- ---- 7.00 / 23,800
HKR10A,CA
46 / 53 60 / 60 ---- ---- 9.50 / 32,400
HKR15A,CA
46 / 52 60 / 60 22 / 25 30 / 30 14.25 / 48,600
HKR20A,CA 46 / 52 60 / 60 43 / 49 60 / 60 19.50 / 66,500
Actual
kW & BTU
at 240V
Minimum Circuit
Ampacity
at 208 / 240V
Minimum Circuit
Ampacity
at 208 / 240V
Model and Heat Kit Usage
Circuit #1 Circuit #2
Supply Votage
240 230 220 210 208
Correction Factor
1.0 0.93 0.85 0.78 0.76
Multiply rated kW by correction factor to get actual kW
Heating kW Correction Factor
