COOLING PERFORMANCE DATA
CKF48-5*
MODEL: CKF48-5* / A48-00-2 COOLING OPERATION
Outdoor Ambient Temperature
65 75 85 95 105 115 118°F 125°F
Entering Indoor Wet Bulb Temperature
IDB*Airflow 596367715963677159 63 677159 63 67 71596367715963677159 53 67 71 59 63 67 71
MBh 44.0 44.9 48.0 51.3 43.0 43.9 46.9 50.1 41.9 42.8 45.8 48.9 40.9 41.8 44.7 47.7 38.9 39.7 42.4 45.4 36.0 36.8 39.3 42.0 33.7 34.4 36.8 39.3 32.7 33.4 35.7 38.2
S/T 0.92 0.86 0.70 0.5 0.95 0.89 0.73 0.5 0.97 0.91 0.74 0.6 1.00 0.94 0.77 0.6 1.00 0.98 0.80 0.6 1.00 1.00 0.80 0.6 1.00 1.00 0.83 0.6 1.00 1.00 0.83 0.6
DT 21 21 18 14 22 21 18 14 22 21 18 14 22 21 18 15 21 21 18 14 19 20 17 13.4 18 18 16 12.9 17 18 16 12.6
1732 KW 3.44 3.51 3.62 3.7 3.89 3.98 4.10 4.2 4.27 4.36 4.51 4.7 4.66 4.76 4.92 5.1 5.01 5.12 5.29 5.5 5.34 5.46 5.64 5.8 5.62 5.75 5.94 6.2 5.74 5.87 6.07 6.3
AMPS 9.5 9.6 9.9 10.1 10.0 10.2 10.4 10.7 10.6 10.8 11.1 11.4 11.2 11.4 11.7 12.0 11.7 11.9 12.2 12.6 12.2 12.5 12.8 13.2 12.6 12.8 13.2 13.6 12.7 13.0 13.3 13.7
HI PR 51 54 58 60.0 57 61 65 67.3 65 69 73 76.5 74 79 84 87.2 83 89 94 98.1 91 98 104 108.4 97 104 110 115.1 100 107 113 117.9
LO PR 204 217 237 252.0 215 229 250 266.2 224 238 260 276.7 235 250 273 290.6 246 262 286 304.6 255 271 296 315.0 259 275 301 320.1 261 277 303 322.3
MBh 43.3 44.3 47.3 50.6 42.3 43.2 46.2 49.4 41.3 42.2 45.1 48.2 40.3 41.2 44.0 47.0 38.3 39.1 41.8 44.7 35.5 36.2 38.7 41.4 33.2 33.9 36.3 38.8 32.2 32.9 35.2 37.6
S/T 0.88 0.82 0.67 0.5 0.91 0.85 0.69 0.5 0.93 0.87 0.71 0.5 0.96 0.90 0.74 0.5 1.00 0.94 0.76 0.6 1.00 0.95 0.77 0.6 1.00 0.97 0.79 0.6 1.00 0.98 0.80 0.6
DT 23 22 19 15 23 22 19 15 23 22 19 15 23 22 19 15 23 22 19 15 21 20 18 14.1 20 20 17 13.6 19 19 17 13.3
80 1550 KW 3.42 3.49 3.60 3.7 3.87 3.95 4.08 4.2 4.25 4.34 4.48 4.6 4.63 4.73 4.89 5.1 4.98 5.09 5.26 5.4 5.30 5.42 5.61 5.8 5.59 5.71 5.91 6.1 5.71 5.84 6.04 6.2
AMPS 9.4 9.6 9.8 10.1 10.0 10.1 10.4 10.7 10.6 10.8 11.0 11.3 11.1 11.3 11.6 11.9 11.6 11.9 12.2 12.5 12.2 12.4 12.7 13.1 12.5 12.8 13.1 13.5 12.7 12.9 13.3 13.7
HI PR 50 54 57 59.6 56 61 64 66.8 64 69 73 76.0 73 79 83 86.6 82 88 93 97.4 91 98 103 107.6 96 104 110 114.3 99 106 112 117.1
LO PR 202 215 235 250.2 214 227 248 264.4 222 236 258 274.8 233 248 271 288.6 245 260 284 302.5 253 269 294 312.9 257 273 299 317.9 259 275 301 320.1
MBh 41.2 42.1 44.9 48.0 40.2 41.1 43.9 46.9 39.2 40.1 42.8 45.8 38.3 39.1 41.8 44.7 36.4 37.2 39.7 42.4 33.7 34.4 36.8 39.3 31.5 32.2 34.4 36.8 30.6 31.3 33.4 35.7
S/T 0.84 0.79 0.64 0.5 0.87 0.82 0.67 0.5 0.89 0.84 0.68 0.5 0.92 0.87 0.70 0.5 0.96 0.90 0.73 0.5 0.97 0.91 0.74 0.6 0.99 0.93 0.76 0.6 1.00 0.94 0.77 0.6
DT 23 22 19 15 24 23 20 16 24 23 20 16 24 23 20 16 23 22 20 16 22 21 18 15 21 20 18 14.0 21 20 17 13.7
1368 KW 3.37 3.44 3.54 3.7 3.81 3.89 4.01 4.1 4.18 4.27 4.41 4.6 4.55 4.66 4.81 5.0 4.90 5.01 5.17 5.3 5.21 5.33 5.51 5.7 5.49 5.62 5.81 6.0 5.61 5.74 5.93 6.1
AMPS 9.3 9.5 9.7 9.9 9.8 10.0 10.2 10.5 10.4 10.6 10.9 11.2 11.0 11.2 11.4 11.8 11.5 11.7 12.0 12.3 12.0 12.2 12.5 12.9 12.3 12.6 12.9 13.3 12.5 12.7 13.1 13.4
HI PR 49 53 56 58.4 55 59 63 65.5 63 68 71 74.5 72 77 81 84.8 81 87 92 95.4 89 96 101 105.5 94 102 107 112.0 97 104 110 114.8
LO PR 198 211 230 245.2 209 223 243 259.1 218 232 253 269.3 229 243 266 282.8 240 255 278 296.4 248 264 288 306.6 252 268 293 311.6 254 270 295 313.7
MBh 44.7 45.6 47.8 51.0 43.7 44.6 46.7 49.8 42.7 43.5 45.5 48.6 41.6 42.4 44.4 47.4 39.5 40.3 42.2 45.0 36.6 37.3 39.1 41.7 34.3 35.0 36.6 39.1 33.3 33.9 35.5 37.9
S/T 0.96 0.93 0.84 0.7 1.00 0.96 0.87 0.7 1.00 0.99 0.89 0.7 1.00 1.00 0.92 0.7 1.00 1.00 0.95 0.8 1.00 1.00 0.96 0.8 1.00 1.00 0.99 0.8 1.00 1.00 1.00 0.8
DT 23 22 21 18 23 23 21 19 23 23 22 19 22 23 22 19 21 21 21 18 19 20 20 17.3 18 19 19 16.6 18 18 19 16.3
1732 KW 3.47 3.54 3.65 3.8 3.92 4.01 4.13 4.3 4.31 4.40 4.54 4.7 4.70 4.80 4.96 5.1 5.05 5.17 5.34 5.5 5.38 5.50 5.69 5.9 5.67 5.80 6.00 6.2 5.79 5.92 6.13 6.3
AMPS 9.5 9.7 9.9 10.2 10.1 10.2 10.5 10.8 10.7 10.9 11.2 11.5 11.2 11.4 11.7 12.1 11.8 12.0 12.3 12.7 12.3 12.6 12.9 13.3 12.7 12.9 13.3 13.7 12.8 13.1 13.4 13.8
HI PR 51 55 58 60.6 57 62 65 68.0 65 70 74 77.3 74 80 84 88.0 84 90 95 99.1 92 99 105 109.4 98 106 111 116.2 101 108 114 119.1
LO PR 206 219 239 254.5 217 231 252 268.9 226 240 262 279.5 237 252 276 293.5 249 265 289 307.6 257 274 299 318.2 261 278 304 323.3 263 280 306 325.5
MBh 44.1 44.9 47.1 50.2 43.1 43.9 46.0 49.0 42.0 42.8 44.9 47.9 41.0 41.8 43.8 46.7 39.0 39.7 41.6 44.4 36.1 36.8 38.5 41.1 33.8 34.4 36.1 38.5 32.8 33.4 35.0 37.4
S/T 0.92 0.89 0.80 0.7 0.95 0.92 0.83 0.7 0.98 0.94 0.85 0.7 1.00 0.97 0.88 0.7 1.00 1.00 0.91 0.7 1.00 1.00 0.92 0.7 1.00 1.00 0.95 0.8 1.00 1.00 0.96 0.8
DT 24 24 22 19 24 24 23 20 24 24 23 20 24 24 23 20 23 24 23 19 21 22 21 18.2 20 20 20 17.5 19 20 20 17.2
85 1550 KW 3.45 3.52 3.63 3.7 3.90 3.98 4.11 4.2 4.28 4.38 4.52 4.7 4.67 4.77 4.93 5.1 5.02 5.14 5.31 5.5 5.35 5.47 5.66 5.9 5.63 5.76 5.96 6.2 5.76 5.89 6.09 6.3
AMPS 9.5 9.6 9.9 10.1 10.0 10.2 10.4 10.7 10.7 10.8 11.1 11.4 11.2 11.4 11.7 12.0 11.7 11.9 12.3 12.6 12.3 12.5 12.8 13.2 12.6 12.9 13.2 13.6 12.8 13.0 13.3 13.8
HI PR 51 55 58 60.2 57 61 65 67.5 65 70 74 76.8 74 79 84 87.4 83 89 94 98.4 92 99 104 108.7 97 105 111 115.4 100 107 113 118.3
LO PR 204 217 237 252.7 216 230 251 267.0 224 239 261 277.5 236 251 274 291.5 247 263 287 305.5 255 272 297 316.0 260 276 301 321.1 261 278 304 323.3
MBh 41.9 42.7 44.7 47.7 40.9 41.7 43.7 46.6 39.9 40.7 42.6 45.5 39.0 39.7 41.6 44.4 37.0 37.7 39.5 42.2 34.3 34.9 36.6 39.0 32.1 32.7 34.3 36.6 31.2 31.8 33.3 35.5
S/T 0.88 0.85 0.77 0.6 0.91 0.88 0.80 0.6 0.94 0.90 0.82 0.7 0.97 0.93 0.84 0.7 1.00 0.97 0.87 0.7 1.00 0.98 0.88 0.7 1.00 0.99 0.91 0.7 1.00 1.00 0.92 0.7
DT 25 24 23 20 25 25 23 20 25 25 23 20 25 25 24 20 25 25 23 20 23 23 22 18.8 22 22 21 18.0 21 21 20 17.7
1368 KW 3.39 3.46 3.57 3.7 3.84 3.92 4.04 4.2 4.21 4.30 4.44 4.6 4.59 4.69 4.85 5.0 4.94 5.05 5.22 5.4 5.26 5.38 5.56 5.7 5.54 5.66 5.86 6.1 5.66 5.79 5.98 6.2
AMPS 9.4 9.5 9.7 10.0 9.9 10.1 10.3 10.6 10.5 10.7 11.0 11.3 11.0 11.2 11.5 11.8 11.6 11.8 12.1 12.4 12.1 12.3 12.6 13.0 12.4 12.7 13.0 13.4 12.6 12.8 13.2 13.5
HI PR 50 54 57 59.0 56 60 63 66.1 63 68 72 75.2 72 78 82 85.7 81 88 92 96.4 90 97 102 106.5 95 103 108 113.1 98 105 111 115.9
LO PR 200 213 233 247.7 212 225 246 261.7 220 234 255 272.0 231 246 268 285.7 242 257 281 299.4 250 266 291 309.7 254 271 295 314.7 256 272 297 316.8
Shaded area is AHRI Rating Conditions IDB: Entering Indoor Dry Bulb Temperature KW=Total system power AMPS=outdoor unit amps (comp.+fan)
High and low pressures are measured at the liquid and suction service valves.
EXPANDED PERFORMANCE DATA
