WARNING
• Make sure doorway is in view and clear of obstacles
and people to avoid injury or damage to property.
• DO NOT operate this unit from wall console before
LIMITS and FORCE are set. Severe damage to the
opener can occur.
• The bullet MUST be engaged to carriage BEFORE
setting limits. See Installation Poster (if provided) or
refer to pages 11 and 19.
NOTE: If bullet has NOT been engaged to
the carriage, do so now.
©2011 The Genie Company 3/2011
6
PROGRAM
SET
—
+
SETTING & TESTING LIMITS AND FORCE
The OPEN (UP) and CLOSE (DOWN) Door Limit positions are controlled by making
adjustments using the panel located on the bottom of the powerhead. Begin with
Step 1 and continue through Step 10. Door Force is set during the final Open/Close
cycle of these steps. The powerhead will automatically set door speed at slow if the
distance between limits is less than 6 feet. Once Limits and Force are set DO NOT use
the
or buttons to open or close door.
A) CLOSE DOOR TRAVEL LIMIT
NOTE: You can start and stop door
movement using either
buttons until
door is in correct open or closed position.
Watch door move
PROGRAMMING LIMITS & FORCE
(Continuing from Installation Poster if provided)
1
G
RAM
SE
—
+
5
PROGRAM
SET
—
+
PRESS and HOLD
SEE BOTH
Blue LEDs
come ON
SEE round
Blue LED
come ON
SEE round Blue
LED flashing
RELEASE
1
2 3
4
NOTE: If one or both LEDs come ON RED
at this time, Limits programming menu
was not entered properly. You must exit
programming and restart.
To exit the programming function wait 30
seconds for the programming to time out.
PRESS and RELEASE
Please note that there is a 30 second timeout
between each programming step.
A programming timeout during these steps has
occured when two RED flashing LEDs appear.
In the event of a timeout please restart at Step 1.
OT CE
O
R
CO
S
S
R
T
D
P
O
W
O
DE
PROGRAM
SET
—
PRESS and
RELEASE
SEE long Blue
LED come ON
If RED LED comes ON - STOP and
exit programming.
PRESS and HOLD until door is FULLY CLOSED then RELEASE
