Detector reset function
This function is used to reset Smoke Detectors and Zone Troubles. Your system must be Disarmed to use
the Reset function.
Step 1 Press [r]-[7]. Resets have now been performed. The FIRE light will go off if the smoke
detectors have been reset.
Step 2 If the keypad begins beeping, the reset did not execute properly. Enter your code to silence
the keypad. Wait a few minutes and repeat step 2 to attempt another reset. If the keypad still
beeps after repeated attempts, please contact your installer.
Setting the system clock
Step 1 Enter [r][9][7].
Step 2 Enter [master code].
Step 3 Enter the “hour code” which must be two (2) digits.
Note: The clock is a 24-hour clock. Refer to the following table.
Time Hour Code Time Hour Code Time Hour Code
12:00 Midnight 00 8:00 AM 08 4:00 PM 16
1:00 AM 01 9:00 AM 09 5:00 PM 17
2:00 AM 02 10:00 AM 10 6:00 PM 18
3:00 AM 03 11:00 AM 11 7:00 PM 19
4:00 AM 04 12:00 Noon 12 8:00 PM 20
5:00 AM 05 1:00 PM 13 9:00 PM 21
6:00 AM 06 2:00 PM 14 10:00 PM 22
7:00 AM 07 3:00 PM 15 11:00 PM 23
Step 4 Enter the “minutes code” which must be two (2) digits.
Example: 7 minutes after would be entered [0] – [7].
NX-108/116/124E User manual Page 14 04/10/04
