170 Saving the meter configuration
Section 5: Startup and meter configuration Reference, Installation, and Operations Manual
June 2013 3-9000-743 Rev S
5.8 Saving the meter configuration
It is recommended that, following meter set-up, the meter configuration be saved to a file for
future reference. To save the configuration file,
1. Use the
Tools}Edit/Compare Configuration menu.
2. Click the
Meter Read button and, after the configuration data points are read, click the
File Save button.
Reverse C1 Data points affected:
• RevC1
Options:
• Enter a value (dimensionless) within the range [0.95,1.05].
Guidelines:
• For additional guidelines, see Section 6.1.8 and Daniel MeterLink online help.
Reverse C2 Data points affected:
• RevC2
Options:
• Enter a value (s/m or s/ft) within the range [-0.1,0.1 s/m].
Guidelines:
• For additional guidelines, see Section 6.1.8 and Daniel MeterLink online help.
Reverse C3 Data points affected:
• RevC3
Options:
• Enter a value (s
2
/m
2
or s
2
/ft
2
) within the range [-0.1,0.1 s
2
/m
2
].
Guidelines:
• For additional guidelines, see Section 6.1.8 and Daniel MeterLink online help.
Table 5-25 Data Points for Polynomial Wet Calibration
Daniel MeterLink
Display Name
Data Points, Options and Guidelines
