ULTRA FLAME DIRECT VENT GAS STOVE 20
MAINTENANCE INSTRUCTIONS
TURN OFF THE GAS WITH THE SHUTDOWN VALVE AND DISCONNECT
THE ELECTRICAL POWER BEFORE SERVICING THE APPLIANCE.
Yearly maintenance
• The venting system and the gas stove should be inspected at least once a year.
• Remove the front glass and the logs and clean them if necessary.
• The control compartment, air circulating passages, firebox, logs and burner should be cleaned at least
once a year by vacuuming or brushing.
• Check the pilot flame to see if it is adjusted properly. Readjust the pilot flame if necessary (as described
below) or clean the pilot orifice if readjustment is not possible.
• Check the burner for flame lifting or for unusual flame pattern. If necessary clean the burner orifice. For
more information, see “Adjustments” in the INSTALLATION section.
• Keep the area clear and free from combustible materials, gasoline and other flammable vapors and
liquids.
Burst Disc Replacement
If the burst disc under the burner moves from its location, it must be put back in place into the silicone seal.
Make sure the switch is depressed all the way during the installation. Otherwise the appliance will not
operate.
ATTENTION
• Never glue or lubricate the disc to the silicone seal.
• Do not put any object under the disc.
Bay window
We have supplied your ULTRA FLAME with special ceramic glass, which will withstand the heat from the unit
without cracking. Be careful not to hit the glass.
Cleaning
• Never clean this glass with abrasive cleaners ;
• Use only a cleaner recommended by your
dealer.) ;
• Never clean glass while it is still hot.
• Do not operate the stove with the glass broken
or removed
Repairing
• Ask your Drolet dealer to provide to you an
appropriate replacement glass.
• Remove the bay window
• Remove front as explained above. With a 5/16”
nut driver remove all nuts holding the glass
retainers. Carefully remove retainers and seal.
• If the gasket is damaged, replace it with a
identical one.
• To get a new gasket, refer to you DROLET
dealer.
