Operator's Manual -FOCUS S17/L17 and S20/L20 Page -5-
EN
Model FOCUS S17 Rotary
Machine Power Supply 24 Volt D.C., (2) 12V 130AH Wet 24 Volt D.C., (2) 12V 130AH Wet
or (2) 12V 100AH Gel Deep Cycle Batteries or (2) 12V 100AH Gel Deep Cycle Batteries
Pad or Brush 3-Lug Driver Style 3-Lug Driver Style
Traverse Brush Assist 1/3 HP (0.25 kW)
Traverse Forward Speed Not Applicable Variable to 200 ft./min (61 m/min)
Traverse Reverse Speed Not Applicable Variable to 140 ft./min. (43 m/min)
Battery Protection Low Voltage Cut-Off of Brush and Solution
Motor Vacuum 3/4 HP(.569 kW) Acoustical High Efficient Tangential 3 stg
Solution Tank 11 Gallons (42 liters)
Solution Level Calibrated Level Indicator
Recovery Tank 11 Gallons (42 liters)
Recovery Full Indicator Electric Shut-Off
Parabolic Squeegee Swing type with breakaway feature, No tool operation feature,
32" (81cm) hard width with 34" (86cm) flex blade width
Squeegee Operation Reverse direction on floor and 3 - position manual lever style operation
Cleaning Swath 17" (43.2 cm)
Motor, Brush 3/4 HP (0,56 kW) 5.2:1 High Torque Gear Box
Brush / Pad Size 17" (43.2 cm)
Brush Speed 200 RPM
Brush Pressure 0-90 lbs. (0-40.8 kg)
Brush Solution Retention Fiber Bristles
Drive Wheels (2) 8" x 2" (20 cm x 5 cm) Neoprene tread
Caster 3½" X 1¼" (8.9 cm x 3.2 cm)
On-Board Charger 24 V D.C., 10 Amp, 115/60 or 24 V D.C., 10 Amp, 230/50
Grade Cleaning 2%
Length 48
3
/4" (123.8 cm)
Width 19" (48.3 cm)
Height 42" (106.7 cm)
Weight w/batteries (130AH) 327 lbs. (148.3 kg) 345 lbs. (156.5 kg)
Shipping Weight w/Batteries (130AH)
454 lbs. (206 kg) 472 lbs. (214 kg)
Line of Sight (Operator Height = 5'8")
7.5 feet (2.3 m)
Warranty Machine 3 Years, Polydur tanks 8 Years, Batteries 18 Months Pro-rated
FOCUS L17 Rotary
Model FOCUS L17 Cylindrical
Machine Power Supply 24 Volt D.C., (2) 12V 130AH Wet
or (2) 12V 100AH Gel Deep Cycle Batteries
Traverse 1/3 HP (0.25 kW)
Traverse Forward Speed Variable to 200 ft./min (61 m/min)
Traverse Reverse Speed Variable to 140 ft./min. (43 m/min)
Battery Protection Low Voltage Cut-Off of Brushes and Solution
Motor Vacuum 3/4 HP(.569 kW) Acoustical High Efficient Tangential 3 stg.
Solution Tank 11 Gallons (42 liters)
Solution Level Calibrated Level Indicator
Recovery Tank 11 Gallons (42 liters)
Recovery Full Indicator Electric Shut-Off
Parabolic Squeegee Swing type with breakaway feature, No tool operation feature,
32" (81cm) hard width with 34" (86cm) flex blade width
Squeegee Operation Reverse direction on floor and 3 - position manual lever style operation
Cleaning Swath 17" (43.2 cm)
Motor, Brush (2) 3/4 HP (0,56 kW)
Brush 2 per Machine (2) 4" (10 cm)
Brush Speed 1000 RPM
Brush Pressure 70 lbs. (31.8 kg)
Drive Wheels (2) 8" x 2" (20 cm x 5 cm) Neoprene tread
Caster 3½" X 1¼" (8.9 cm x 3.2 cm)
On-Board Charger 24 V D.C., 10 Amp, 115/60 or 24 V D.C., 10 Amp, 230/50
Grade Cleaning 2%
Length 48 ¼" (122.6 cm)
Width 20" (50.8 cm)
Height 42" (106.7 cm)
Weight w/batteries (130 AH) 360 lbs. (163.3 kg)
Shipping Weight w/Batteries (130AH)
487 lbs. (221 kg)
Line of Sight -Operator Height = 5'8"
7.5 feet (2.3 m)
Warranty Machine 3 Years, Polydur tanks 8 Years, Batteries 18 Months Pro-rated
