V9 Series Burner Schedule
OIL BURNERS
Standard Burner Motor Voltage:
Beckett–CF500,CF800,CF1400,andCF2300Aare120/60/1.CF2500Ais240/60/1.
Carlin–301CRDand702CRDare120/60/1.801CRDis240/60/1.
Power Flame–C1-OSis120/60/1.C2-OASandC2-OBare240/60/1.
Webster–JB1O-02,JB1O-03,andJB1O-05are120/60/1.JB1O-07is240/60/1.
GAS BURNERS*
Standard Motor Voltage:
Beckett–V903throughV911120/60/1,V912240/60/1
Power Flame C Series –C1-G-10,C1-G-12,C2-G-15are120/60/1.C2-G-20AandC2-G-20Bare240/60/1.
Power Flame JR Series–Allburnersare120/60/1.
Webster–JB1G-02,JB1G-03andJB1G-05are120/60/1.JB1G-07is240/60/1.
GAS/OIL BURNERS
Standard Burner Motor:
Power Flame–C1-GO-10andC1-GO-12are120/60/1.C2-GO-15,C2-GO-20AandC2-GO-20Bare240/60/1.
Webster–JB1C-02,JB1C-03,andJB1C-05are120/60/1.JB1C-07andJB1C-10are240/60/1.
BOILER
MODEL
BECKETT CARLIN POWER FLAME WEBSTER
BURNER
MODEL H.P.
BURNER
MODEL H.P.
BURNER
MODEL H.P.
BURNER
MODEL H.P.
V903A
V904A
V905A
V906A
V907A
V908A
V909A
V910A
V911A
V912A
CF500
CF800
CF800
CF1400
CF1400
CF1400
CF2300A
CF2300A
CF2500A
CF2500A
1/3
1/3
1/3
1/2
1/2
1/2
3/4
3/4
2
2
301CRD
301CRD
301CRD
702CRD
702CRD
702CRD
801CRD
801CRD
801CRD
801CRD-B
1/4
1/4
1/4
1/2
1/2
1/2
3/4
3/4
3/4
1-1/2
Ñ
C1-OS
C1-OS
C1-OS
C1-OS
C2-OAS
C2-OAS
C2-OAS
C2-OB
C2-OB
Ñ
1/3
1/3
1/2
1/2
3/4
3/4
3/4
1-1/2
1-1/2
Ñ
Ñ
JB1O-02
JB1O-03
JB1O-03
JB1O-03
JB1O-05
JB1O-05
JB1O-07
JB1O-07
Ñ
Ñ
1/4
1/3
1/3
1/3
1/2
1/2
3/4
3/4
BOILER
MODEL
BECKETT
POWER FLAME*
C SERIES
POWER FLAME
JR SERIES WEBSTER
BURNER
MODEL H.P.
MIN. GAS
PRESSURE
INCHES
BURNER
MODEL H.P.
BURNER
MODEL H.P.
MIN. GAS
PRESSURE
INCHES
BURNER
MODEL
MIN. GAS
PRESSURE
INCHES
V903A
V904A
V905A
V906A
V907A
V908A
V909A
V910A
V911A
V912A
CG10-1S
CG10-4S
CG10-5S
CG10-6S
CG15-3S
CG15-4S
CG25-2S
CG25-3S
CG25-4S
CG50-2S
1/3
1/3
1/3
1/3
1/2
1/2
3/4
3/4
3/4
2
3.3
3.7
4.7
5.5
5.4
6.2
4.7
5.0
4.9
3.9
Ñ
C1-G-10
C1-G-10
C1-G-12
C1-G-12
C2-G-15
C2-G-20A
C2-G-20A
C2-G-20B
C2-G-20B
Ñ
1/3
1/3
1/2
1/2
1/2
3/4
3/4
1
1
JR15A-10
JR30A-10
JR30A-12
JR30A-12
JR50A-15
JR50A-15
JR50A-15
Ñ
Ñ
Ñ
1/4
1/3
1/3
1/3
1/3
1/3
1/3
Ñ
Ñ
Ñ
4.0
4.2
5.9
4.3
5.4
4.4
5.0
Ñ
Ñ
Ñ
Ñ
JB1G-02
JB1G-02
JB1G-02
JB1G-02
JB1G-03
JB1G-05
JB1G-05
JB1G-07
JB1G-07
Ñ
5.0
8.0
5.0
6.0
8.0
6.0
6.0
7.0
9.0
BOILER
MODEL
POWER FLAME - C SERIES WEBSTER**
BURNER
MODEL H.P.
INLET GAS
CONNECTION
INCHES
MIN. GAS
PRESSURE
INCHES
BURNER
MODEL H.P.
INLET GAS
CONNECTION
INCHES
V904A
V905A
V906A
V907A
V908A
V909A
V910A
V911A
V912A
C1-GO-10
C1-GO-10
C1-GO-12
C1-GO-12
C2-GO-15
C2-GO-20A
C2-GO-20A
C2-GO-20B
C2-GO-20B
1/3
1/3
1/2
1/2
3/4
1
1
1-1/2
1-1/2
1
1
1
1
1
1-1/4
1-1/4
1-1/4
1-1/2
4.4
4.4
4.8
5.2
6.4
4.9
5.2
5.4
5.0
Ñ
JB1C-02
JB1C-03
JB1C-03
JB1C-05
JB1C-05
JB1C-05
JB1C-07
JB1C-10
Ñ
1/4
1/3
1/3
1/2
1/2
1/2
3/4
1
Ñ
1-1/4
1-1/4
1-1/2
1-1/2
1-1/2
1-1/2
2
2
V9 Series Burners
Optional Motor Voltage:
Mostmodelshave208-240or480volts/3phaseavailable
at additional cost as an option. Consult your Burnham
Commercial sales representative.
Optional Burner Motor Voltage:
Mostmodelshave208-240or480volts/3phase
available at additional cost as an option. Consult your
Burnham Commercial sales representative.
*ForgasconnectionsizeonGordon-Piatt,Websterand
PowerFlameCburnersandminimumgaspressure
for C burner see gas/oil burner chart.
Optional Burner Motor Voltage:
Mostmodelshave208-240or480volts/
3phase available at additional cost as an
option. Consult your Burnham Commercial
sales representative.
**Forminimumgaspressure
requirements, see gas burner chart.
