SBC
ª
Boiler Control System
Exclusive Optional Feature for Burnham Commercial Boilers
Boiler Monitoring & Diagnostic Displays
•Two-linebysixteencharacterLCDdisplay
•Automaticallypresents
boiler sequence, alarm,
hold and lockout messages
•Diagnosticmenudisplays
thelast10alarmmessages
and the boiler return
temperature alarm history
Modulation Rate and
On/Off Modes
•Controlstheboiler
modulation and on/ off
output based on the supply water temperature and an
operator adjusted setpoint
•Canrespondtoremotesystemwater,outsideair
temperatures,DomesticHotWaterPriority(DHWP)or
Energy Management Systems (EMS)
Outdoor Air Temperature Reset
•Savesfuelbyreducingthesupplytemperatureofa
heating boiler as the outside air temperature increases
Warm Weather Shutdown (WWSD)
•Preventstheboiler,boilerpumpand/orthesystem
pump from starting during warm weather
Domestic Hot Water Priority (DHWP)
•Continuoussupplyofhotwater,evenduringwarmer
months
System Control Outputs
•Fullyintegratedautomationofmixingvalves,boiler
pumps, system pumps, and standby system pumps
•Controlparametersareeldselectablethroughsimple
yes/no menu selections
The SBC Boiler
Control SystemÉ
Only available from
Burnham Commercial!
Advanced Adaptability
•Easilyintegratedintoexistingornewbuilding
management systems
•Simpliedconnectionsavailabletomostbuilding
management systems through Modbus
¨
or
standard0-10voltsignals
•UsessophisticatedPIDcontrollogicforcomplete
boiler system control
•Performscontrolfunctionsforbothsingleand
multiple boilers
Peer-To-Peer Network
•Includeslead-lagsequencerforuptoeight(8)fully
modulating boilers
•Capableofautorotation,outdoorresetand
peer-to-peer communication
•“Plugandplay”communicationbysimply
connectingaRJ11telephonelinebetweenboilers
•Providespreciseboilercoordinationbysequencing
boilers based on both remote system water
temperature and boiler modulation rate.
•Boilersaremodulatedin“unison”,allatthesame
firing rate to ensure even heat distribution
Fail-Safe System Operations
•Allowscontinuedboileroperationintheeventof
selected sensor failure or building management
system failure
SBC Exclusives
SBC
Integrated Boiler Control System
The Burnham Commercial SBC is a complete boiler monitoring and
automation system. Available as an option, this exclusive feature
was developed by Burnham Commercial engineers and is designed
specifically for use on Burnham Commercial boilers.
Designedtomaximizesystemefciencyandminimizeenergyusage
Easily connected to building management systems
Provencontrolplatform
Fail-safedesigninsuresboileroperation
POWER
