Burnham 20_PV_I Boiler User Manual



26
Key
No.
Description
[Quantity] Part Number
203PV 204PV 205PV 206PV
3. Base Assembly Group
3 Base Assembly, Complete [1] 618600391 [1] 618600491 [1] 618600591 [1] 618600691
3A Base Tray Assembly [1] 718600391 [1] 718600491 [1] 718600591 [1] 718600691
3B Base Wrapper [1] 718600311 [1] 718600411 [1] 718600511 [1] 718600611
3B1 Base End Insulation [2] 720601
3B2 Base Rear Insulation [1] 72060035 [1] 72060045 [1] 72060055 [1] 72060065
3C Base Front Panel Assembly [1] 618600341 [1] 618600441 [1] 618600541 [1] 618600641
3D Burner Tray [1] 718600305 [1] 718600405 [1] 718600505 [1] 718600605
3E Base Leg Assembly [4] 6186001
3E1 Base Leg [4] 71860021
3E2 Nylon Glide 8186006
3F Burner Access Panel [1] 718600361 [1] 718600461 [1] 718600561 [1] 718600661
3G Jacket Attachment Bracket, Left [1] 70460011
3H Jacket Attachment Bracket, Right [1] 70460012
3J
Cerafelt Gasket, ½" x 2"
Johns-Mansville CRF-400
[1] 6206002
3K
Screw, Self-Tapping Type F, Phillips Pan
Head, ¼-20 x ½", Plated
[20] 80860700
3L Screw, Self Tapping, 5/16"-18 x 1¼" [4] 80860717
3M Flat Washer, 5/16" [4] Common Hardware
3N Hex Lock Nut, 5/16"-18 [4] 80860464
3P Screw, Sheet Metal, Phillips Head, #8 x ½" [2] Common Hardware
