BW TECHNOLOGIES GAS/ALERT/MICRO 5
MULTI-GAS DETECTORS
GasAlertMicro 5
Portable gas detector simultaneously monitors and displays up to five
potential atmospheric hazards including O2, LEL and a range of toxic
gases. Compact and lightweight, GasAlertMicro 5 comes housed in IP66
concussion-proof enclosure. Audible, visual and vibrator alarms activate
in the event of a low, high, TWA or STEL alarm condition. An optional
motorized pump is available for remote sampling. Beyond features that
come standard with BW portable instruments such as confidence beep,
full function self test, automatic calibration and passcode protection,
GasAlertMicro 5 offers an extended selection of user-settable field
options including: stealth mode, backlight options, selectable ppm resolu-
tion, STEL / TWA measurement choice, combustible correction factors,
user-settable calibration gas concentrations and multi-language support.
• Compact (5.7” x 2.9” x 1.5”) and lightweight
• Rugged, highly water-resistant design
• Continuous LCD shows simultaneous gas concentra-
tions for up to five gases
• Integral concussion-proof enclosure for the most
rugged environments
• Integral motorized pump option for remote sampling
(optional)
• Two power options: three AA alkaline batteries or a
rechargeable battery pack
• Provides 95 dB alarm tone (typical), two bright wide-
angled alarm bars and internal vibrating alarm for high
noise areas
• Multiple language support in English, French, German,
Spanish and Portuguese
• Four alarm levels: instantaneous Low and High Alarm
for all gases; TWA (time weighted average) and STEL
(short term exposure limit) for toxic gases
• Simple automatic cali-
bration procedure;
compatible with BW
MicroDock II system
• Records TWA, STEL
and maximum exposures to gas and displays readings
on command
• User selectable field options include: confidence beep,
pass code protection, latching alarm, calibration due
date and “SAFE” display function, stealth mode, span
level, selectable ppm resolution for some gases (e.g.
SO2 0.1 ppm)
• Full function self-test of: sensor, battery and circuit
integrity; and audible/visual alarms
• Two year warranty; including sensors
• GasAlertMicro 5 PID version also available
Ordering Information:
Part No. Description
M5-XWSY-A-D-0-Y-N-00 5-gas detector, combustibles, oxygen,
carbon monoxide, hydrogen sulfide, and
sulphur dioxide, with AA batteries
M5-XWSY-R-D-0-Y-N-00 5-gas detector, combustibles, oxygen
carbon monoxide, hydrogen sulfide, and
sulphur dioxide, with rechargeable battery
pack
M5-XWOY-A-D-0-Y-N-00 4-gas detector, combustibles, oxygen,
carbon monoxide, and hydrogen sulfide,
with AA batteries
M5-XWOY-R-D-0-Y-N-00 4-gas detector, combustibles, oxygen,
carbon monoxide, and hydrogen sulfide,
with rechargeable battery pack
Note: Also available with optional motorized pump - replace suffix: 0-
Y-N-00 with 0-Y-N-00-A-D.
Features:
Complete Specifications Available Upon Request
Packaging Contents:
Standard Versions: Complete with monitor
and sensors (as specified), sensor
compartment cover for diffusion opera-
tion, calibration adapter and hose, quick
reference guide, interactive training and
technical documentation CD, integral
concussion-proof boot and 3 AA alkaline
batteries.
Confined Space Kits: Include standard
version contents plus foam lined carrying
case for instrument and accessories, 34L
cylinder(s) of calibration gas, 1.0 LPM
calibration regulator (male) and tubing.
Motorized Pump Units: Include standard
version contents plus motorized pump
and cover (installed), 12 in. / 30 cm
sample probe with hydrophobic barrier
(water trap) and particulate filters, 10 ft. /
3 m sample tubing, five spare particulate
filters and one spare water trap filter.
