AXIS Q7401 Video Encoder
Technical Specifications
Function/group
Item
Specications
Application
Programming
Interface
Open API for software integration, including VAPIX® from Axis Communications available
at www.axis.com
Includes the ONVIF Prole S; specication at www.onvif.org Support for AXIS Video
Hosting System (AVHS) with One-Click Camera connection
Intelligent video
Video motion detection, active tampering alarm, audio detection, Support for AXIS
Camera Application Platform enabling installation of additional applications
Event triggers Intelligent video, Audio detection, external inputs, edge storage events
System
Integration
Events actions File upload via FTP, HTTPP, network share and email
Notication via email, HTTP and TCP
PTZ preset
External output activation
Play audio clip
Pre- and post-alarm video buffering
Casing Metal casing. Standalone or wall mount
Processor,
memory
ARTPEC-3
128 MB RAM
128 MB Flash
Battery backed-up real-time clock
Power
8-20 V DC, max. 7.2 W or Power over Ethernet IEEE 802.3af Class 2/3
Connectors
Analog composite video BNC input, NTSC/PAL auto-sensing
RJ-45 10BASE-T/100BASE-TX PoE
DC terminal block: power in 8-20 V DC, max. 7.2 W or power out 12 V DC, max. 5 W
I/O terminal block for four congurable inputs/outputs
3.5 mm mic/line in, 3.5 mm line out
RS-485/ RS-422
Edge storage
SD/SDHC memory card slot (card not included)
Support for recording to network share (network-attached storage or le server)
Operating
conditions
0 – 50 °C (32 – 122 °F)
Humidity 20 – 80% RH (non-condensing)
Approvals
EN 55022 Class B
EN 61000-3-2
EN 61000-3-3
EN 55024
EN 61000-6-1
EN 61000-6-2
FCC Part 15 Subpart B Class B
ICES-003 Class B
VCCI Class B
C-tick AS/NZS CISPR 22 Class B
IEC/EN/UL 60950-1
Power supply PS-T: EN 60950-1, CSA, C/US
Power supply PS-K: EN 60950-1, UL, cUL
Weight
335 g (0.7 lb.)
General
Included
accessories
Power supply, mounting and connector kits, Installation Guide, CD with installation and
management tools, software and User Manual, 1 Windows decoder user license
Dimensions
(HxWxD)
94 x 144 x 132 mm (3.7" x 5.7" x 5.2")
63
