840569-YTG-A-0612
Johnson Controls Unitary Products 7
— = Not applicable.
MA Modular Air Handlers use Coil Only Ratings.
YCJD48S41S1(H)(E)
AHE48D 24.5 – 1600 47.0 34.6 13.75 11.50
AHP48 24.5 – 1675 48.0 34.4 13.00 11.00
AHP60 24.5 – 1600 48.0 35.0 13.50 11.00
AHR48D 24.5 – 1610 48.0 34.6 13.00 11.00
AHX48 24.5 – 1660 48.0 35.4 13.50 11.50
AV*48 24.5 – 1625 48.0 35.0 13.50 12.00
AV*60 24.5 – 1560 48.0 35.0 13.50 12.00
F4FV060 24.5 – 1600 48.0 34.6 14.00 11.50
F5FP048 24.5 – 1600 48.0 34.4 13.00 11.00
F5FP060 24.5 – 1600 48.0 34.4 13.00 11.00
F6FP048 24.5 – 1625 47.0 34.8 13.00 11.30
MV16C 21.0 FC/MC48C 1600 48.0 35.0 13.50 12.00
MV16C 21.0 FC60C 1625 47.5 34.6 13.50 11.50
MV20D 24.5 FC/MC48D 1600 48.0 35.0 13.50 12.00
MV20D 24.5 FC/MC60D 1600 48.0 35.0 13.50 12.00
MX16C 21.0 FC/MC48C 1685 48.5 35.6 13.75 11.50
MX20D 24.5 FC/MC48D 1525 48.0 34.2 14.00 11.75
MX20D 24.5 FC/MC60D 1585 48.5 34.6 14.00 12.00
YCJD60S41S1(E)
AHE60D 24.5 – 1835 58.5 39.8 13.50 11.50
AHP60 24.5 – 1850 57.0 38.5 13.00 11.00
AHR60D 24.5 – 1870 57.0 38.5 13.00 11.00
AHX60 24.5 – 1905 58.5 40.0 13.50 11.50
AV*60 24.5 – 1730 58.0 39.0 13.50 11.00
F4FV060 24.5 – 1780 57.0 38.5 13.50 11.00
F5FP060 24.5 – 1900 57.0 38.5 13.00 11.00
F6FP060 24.5 – 1710 57.5 39.0 13.50 11.50
MV20D 24.5 FC/MC60D 1800 57.0 38.5 13.00 11.00
MV20D 24.5 FC/MC62D 1800 57.0 38.5 13.00 11.00
MV20D 24.5 FC64D 1855 57.0 39.0 13.75 11.50
MX20D 24.5 FC/MC60D 1780 57.5 38.8 13.75 11.50
MX20D 24.5 FC/MC62D 1795 58.0 38.8 14.00 11.75
MX20D 24.5 FC64D 1795 58.5 39.8 14.50 12.00
Rated in accordance with DOE test procedures (Federal Register 12-27-79 and 3-18-88) and ANSI/AHRI Standard 210/240.
Cooling MBH based on 80°F entering air temperature, 50% RH (Relative Humidity), and rated air flow.
EER (Energy Efficiency Ratio) is the total cooling output in BTUs at 95°F outdoor ambient divided by the total electric power in watt-hours at those conditions.
SEER (Seasonal Energy Efficiency Ratio) is the total cooling output in BTUs during a normal annual usage period for cooling divided by the total electric power input in
watt-hours during the same period.
1. MC coils available with a factory installed horizontal drain pan. See price pages for specific model number.
COOLING CAPACITY - With Air Handler Coils (Continued)
UNIT
MODEL
AIR HANDLER
COIL
MODEL
1
COOLING
MODEL WIDTH
RATED
CFM
NET MBH
SEER EER
TOTAL SENS.
13 SEER AC WITH AIR HANDLERS
