Electrical Data - 60Hz
YCAL0041 - YCAL0065
SINGLE POINT FIELD SUPPLIED POWER WIRING (See Fig. 2)
(One Field Provided Power Supply to the chiller. Field connections to Factory Provided Power Terminal Block (standard), Non-Fused Discon-
nect Switch (optional) or Circuit Breaker (optional).)
See Notes on page 100.
MODEL
YCAL
VOLT
MCA
1
MIN N/F
DISC
SW
2
D.E. FUSE CKT. BKR.
5
FIELD WIRING LUGS
6
TERMINAL BLOCK (std)
FIELD WIRING LUGS
6
NF DISC. SWITCH (opt)
REC. MAX
4
REC. MAX
LUGS/
PHASE
LUG WIRE RANGE
LUGS/
PHASE
LUG WIRE RANGE
0041
200 197 250 225 225 225 225 1 6awg - 500MCM 1 6awg - 350MCM
230 184 250 200 200 200 200 1 6awg - 500MCM 1 6awg - 350MCM
380 107 150 125 125 125 125 1 6awg - 500MCM 1 6awg - 350MCM
460 90 100 100 100 100 100 1 6awg - 500MCM 1 6awg - 350MCM
575 71 100 80 80 80 80 1 6awg - 500MCM 1 6awg - 350MCM
0045
200 199 250 225 225 225 225 1 6awg - 500MCM 1 6awg - 350MCM
230 186 250 200 200 200 200 1 6awg - 500MCM 1 6awg - 350MCM
380 108 150 125 125 125 125 1 6awg - 500MCM 1 6awg - 350MCM
460 91 100 100 100 100 100 1 6awg - 500MCM 1 6awg - 350MCM
575 71 100 80 80 80 80 1 6awg - 500MCM 1 6awg - 350MCM
0051
200 228 250 250 250 250 250 1 6awg - 500MCM 2 3/0 - 250MCM
230 212 250 225 250 225 250 1 6awg - 500MCM 2 3/0 - 250MCM
380 123 150 150 150 150 150 1 6awg - 500MCM 1 6awg - 350MCM
460 103 150 110 110 110 110 1 6awg - 500MCM 1 6awg - 350MCM
575 81 100 90 90 90 90 1 6awg - 500MCM 1 6awg - 350MCM
0055
200 250 400 300 300 300 300 1 6awg - 500MCM 2 3/0 - 250MCM
230 233 400 250 300 250 300 1 6awg - 500MCM 2 3/0 - 250MCM
380 135 150 150 150 150 150 1 6awg - 500MCM 1 6awg - 350MCM
460 113 150 125 125 125 125 1 6awg - 500MCM 1 6awg - 350MCM
575 89 100 100 100 100 100 1 6awg - 500MCM 1 6awg - 350MCM
0061
200 274 400 300 300 300 300 1 6awg - 500MCM 1 250MCM - 500MCM
230 255 400 300 300 300 300 1 6awg - 500MCM 1 250MCM - 500MCM
380 148 200 175 175 175 175 1 6awg - 500MCM 1 6awg - 350MCM
460 125 150 150 150 150 150 1 6awg - 500MCM 1 6awg - 350MCM
575 98 150 110 110 110 110 1 6awg - 500MCM 1 6awg - 350MCM
0065
200 292 400 350 350 350 350 1 6awg - 500MCM 1 250MCM - 500MCM
230 272 400 300 300 300 300 1 6awg - 500MCM 1 250MCM - 500MCM
380 158 200 175 175 175 175 1 6awg - 500MCM 1 6awg - 350MCM
460 132 150 150 150 150 150 1 6awg - 500MCM 1 6awg - 350MCM
575 104 150 110 125 110 125 1 6awg - 500MCM 1 6awg - 350MCM
