Reference, Installation, and Operations Manual Section 5: Startup and meter configuration
3-9000-743 Rev S June 2013
General Page 137
5.6.6 General Page
Figure 5-9 Field Setup Wizard - General Page
1. From the
General Page, choose the desired settings:
• Meter units system (U.S. Customary or Metric)
• Meter time (click the Set Time button to display the Set Time dialog box)
2. To set the meter real-time clock, configure these data points for meter time (listed in
the table below):
• Flow rate time unit:
— Volume/second
— Volume/hour
— Volume/day
• Volume cut-off threshold
Table 5-14 Data Points for Meter Real-Time Clock
Daniel MeterLink
Display Name
Data Points, Options and Guidelines
Meter Time Data points affected:
• RTCSecondsSinceEpochSet
Options:
• Click the SET TIME button to bring up the SET TIME dialog box for setting the
meter clock.
Guidelines:
• For options and guidelines, see Daniel MeterLink online help.
