Chapter 3 53
5. Remove the two screws securing the ODD bracket and remove the ODD bracket from the optical disk drive
module.
IMPORTANT:Do not remove the ODD bezel by pulling on it entirely or damage will occur.
6. Grasp the edge of the bezel and firmly pry the top edge down and outward to remove.
Step Size Quantity Screw Type
ODD Bracket M2*3 2
