92 Chapter 3
Removing the Camera Module
1. Remove the LCD Bezel. See “Removing the LCD Bezel” on page 88.
2. Remove the single securing screw.
IMPORTANT:Be careful when using a sharp tool to remove the cable or camera module. The surface of the
LCD panel can be easily scratched.
3. Remove the bracket from the back cover.
Step Size Quantity Screw Type
Camera Module M2.5*4 1
