94 Chapter 3
Removing the LCD Panel
1. Remove the LCD Bezel. See “Removing the LCD Bezel” on page 88.
2. Remove the two securing screws from the LCD Module.
IMPORTANT:The correct screw sockets are indicated by a mark on the hinge.
3. Grasp the LCD Panel by the hinges and tilt upwards and away to remove the LCD Module.
Step Size Quantity Screw Type
LCD Panel M2.5*4 2
