246653-YTG-E-0108
Johnson Controls Unitary Products 3
LIST OF FIGURES
Fig.# Pg.#
1 HOT WATER PIPING CROSS-SECTION . . . . . . . . . 15
2 HOT WATER COIL - 25 & 30 TON, 1 ROW,
AT 10 GPM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
3 HOT WATER COIL - 25 & 30 TON, 1 ROW,
AT 20 GPM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
4 HOT WATER COIL - 25 & 30 TON, 1 ROW,
AT 30 GPM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
5 HOT WATER COIL - 25 & 30 TON, 1 ROW,
AT 40 GPM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
6 HOT WATER COIL - 40 TON, 1 ROW,
AT 10 GPM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
7 HOT WATER COIL - 40 TON, 1 ROW,
AT 20 GPM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
8 HOT WATER COIL - 40 TON, 1 ROW,
AT 30 GPM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
9 HOT WATER COIL - 40 TON, 1 ROW,
AT 40 GPM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
10 HOT WATER COIL - 25 & 30 TON, 2 ROW,
AT 20 GPM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
11 HOT WATER COIL - 25 & 30 TON, 2 ROW,
AT 40 GPM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
12 HOT WATER COIL - 25 & 30 TON, 2 ROW,
AT 60 GPM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
13 HOT WATER COIL - 25 & 30 TON, 2 ROW,
AT 80 GPM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
14 HOT WATER COIL - 40 TON, 2 ROW, AT 20 GPM. . 23
15 HOT WATER COIL - 40 TON, 2 ROW, AT 40 GPM. . 23
16 HOT WATER COIL - 40 TON, 2 ROW, AT 60 GPM. . 24
17 HOT WATER COIL - 40 TON, 2 ROW, AT 80 GPM. . 24
Fig.#
Pg.#
18 STEAM PIPING CROSS SECTION . . . . . . . . . . . . . . 25
19 STEAM COIL - 25 & 30 TON, 1 ROW . . . . . . . . . . . . 26
20 STEAM COIL - 40 TON, 1 ROW . . . . . . . . . . . . . . . . 26
21 ALTITUDE/TEMPERATURE CONVERSION
FACTOR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
22 FAN PERFORMANCE - 25 TON . . . . . . . . . . . . . . . . 47
23 FAN PERFORMANCE - 30 TON . . . . . . . . . . . . . . . . 49
24 FAN PERFORMANCE - 40 TON . . . . . . . . . . . . . . . . 51
25 POWER EXHAUST - ONE FORWARD CURVE
FAN - 25 TONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
26 POWER EXHAUST - TWO FORWARD CURVED
FANS - 30 & 40 TONS . . . . . . . . . . . . . . . . . . . . . . . . 60
27 CENTER OF GRAVITY . . . . . . . . . . . . . . . . . . . . . . . 78
28 COMPONENT LOCATION . . . . . . . . . . . . . . . . . . . . 80
29 END RETURN, BOTTOM SUPPLY . . . . . . . . . . . . . . 81
30 BOTTOM SUPPLY AND RETURN . . . . . . . . . . . . . . 82
31 BOTTOM RETURN, FRONT & REAR SUPPLY . . . . 83
32 END RETURN, FRONT & REAR SUPPLY . . . . . . . . 84
33 MILLENNIUM OVERHEAD VIEW . . . . . . . . . . . . . . . 85
34 MILLENNIUM MAJOR COMPONENT LAYOUT . . . . 85
35 MILLENNIUM CABINET DOOR CONFIGURATION . 86
36 CLEARANCES - HOOD/ECONOMIZER & MOTOR
DRIVE - SIDE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87
37 CLEARANCES - HOOD/ECONOMIZER & MOTOR
DRIVE - FRONT & END . . . . . . . . . . . . . . . . . . . . . . 87
38 PARTIAL ROOF CURB MODEL 1RC0455P . . . . . . . 88
