Multipliers for determining the performance with other indoor sections.
COOLING PERFORMANCE DATA
AIR CONDITIONER MODEL NO. H1RE030S06
INDOOR COIL MODEL NO. G1UA048S21, 24
CONDENSER
ENTERING AIR
TEMPERATURE
ID CFM 800 1000 1200
ID DB 85 80 75 70 85 80 75 70 85 80 75 70
ID WB 72 67 62 57 72 67 62 57 72 67 62 57
75
T.C. 35.9 32.8 30.2 27.0 36.6 33.5 30.9 27.7 36.9 33.8 31.4 28.1
S.C. 21.2 21.2 20.4 21.4 22.8 22.9 22.0 23.1 23.9 23.9 23.1 24.2
K.W 1.681.701.711.701.681.691.701.701.671.691.701.70
85
T.C. 34.1 31.1 28.6 25.6 34.7 31.7 29.3 26.2 35.0 32.0 29.6 26.6
S.C. 20.6 20.6 19.7 20.8 22.2 22.2 21.4 22.4 23.3 23.3 22.4 23.6
K.W 1.891.891.891.861.891.891.891.871.891.891.891.87
95
T.C. 32.3 29.5 27.1 24.2 32.8 30.0 27.7 24.8 33.1 30.4 28.0 25.2
S.C. 20.0 20.0 19.2 20.1 21.6 21.6 20.8 21.7 22.7 22.7 21.7 22.8
K.W 2.072.052.031.992.072.062.042.002.072.062.052.01
105
T.C. 30.5 27.8 25.6 22.7 30.9 28.3 26.1 23.4 31.1 28.6 26.3 23.9
S.C. 19.4 19.4 18.6 19.4 21.0 21.0 20.1 21.1 22.1 22.1 21.1 22.0
K.W 2.232.192.162.102.232.202.172.122.242.212.182.13
115
T.C. 28.6 26.0 24.0 21.2 29.0 26.5 24.4 22.1 29.3 26.8 24.7 22.5
S.C. 18.8 18.7 17.9 18.7 20.4 20.4 19.4 20.3 21.5 21.4 20.5 20.8
K.W 2.372.322.272.202.382.332.282.232.382.342.292.24
125
T.C. 26.7 24.2 22.3 19.7 27.1 24.7 22.6 20.8 27.5 25.0 23.0 21.1
S.C. 18.2 18.0 17.2 18.0 19.8 19.8 18.8 19.5 20.9 20.7 19.9 19.6
K.W 2.512.452.382.302.532.462.392.342.522.472.402.35
NOTE: ALL CAPACITIES INCLUDE INDOOR FAN HEAT AT 1250 BTUH/1000 CFM.
Air Handler Coil
T.C. S.C. KW
N1AHB1206 G2FD036S17 0.96 0.95 1.01
N1VSB12 G2FD036S17 0.98 0.95 0.94
N1VSB12 G2FD046S17 1.00 0.99 0.91
F2FP045 1.02 0.99 1.00
F2RP/F2FP036 0.99 0.99 0.99
G1UA036S14 0.95 0.92 1.00
G1UA048S21,24 1.00 1.00 1.00
GUA036S17,21 0.95 0.92 1.01
GFA036S17,21 0.95 0.92 1.01
GFD030S17 0.95 0.94 1.01
G1UA048S21,24 1.00 1.00 1.00
G2FD036S17 0.96 0.95 1.01
G2FD036S21 0.96 0.96 0.98
GFD048S21,24 1.01 1.01 1.00
G1HD048S 1.00 0.99 1.00
G1NA036S17L 0.97 0.92 1.00
G1NA042S24W 0.97 0.95 1.00
G1NA048S21D 0.97 0.92 1.00
G1UA036S14 0.95 0.92 1.00
Variable Speed
Furnace
Coil
T.C. S.C. KW
P1DUA12V G1FA036S14 0.96 0.92 0.95
P1DUA12V G1UA036S14 0.96 0.92 0.95
P1DUB16V G2FD036S17 1.00 0.95 0.93
P1XDB12V G2FD036S17 1.01 0.95 1.00
P1XUB12V G2FD036S17 0.97 0.95 0.95
