036-21315-001 Rev. A (0502)
12 Unitary Products Group
Multipliers for determining the performance with other indoor sections.
COOLING PERFORMANCE DATA
AIR CONDITIONER MODEL NO. H2RE048S06
INDOOR COIL MODEL NO. G2FD060S24, G1UA060S21,24
CONDENSER
ENTERING AIR
TEMPERATURE
ID CFM 1400 1600 1800
ID DB 85 80 70 85 80 70 85 80 70
ID WB 72 67 57 72 67 57 72 67 57
75
T.C. 53.3 49.5 45.5 54.3 50.2 46.4 55.2 51.0 47.3
S.C. 33.4 32.6 31.1 35.9 35.0 33.0 38.3 37.4 34.9
K.W 2.76 2.72 2.69 2.77 2.74 2.70 2.77 2.76 2.70
85
T.C. 51.2 47.7 43.9 52.0 48.4 44.8 52.8 49.1 45.7
S.C. 33.1 32.1 30.6 35.4 34.5 32.6 37.7 36.8 34.6
K.W 3.07 3.04 3.01 3.07 3.05 3.02 3.08 3.06 3.03
95
T.C. 49.0 45.9 42.4 49.7 46.5 43.2 50.3 47.2 44.1
S.C. 32.7 31.6 30.0 34.9 33.9 32.2 37.1 36.2 34.4
K.W 3.37 3.35 3.33 3.38 3.36 3.34 3.38 3.37 3.35
105
T.C. 46.6 43.5 40.1 47.3 44.1 40.8 48.0 44.7 41.6
S.C. 31.7 30.7 29.0 34.0 32.9 31.2 36.3 35.1 33.3
K.W 3.78 3.75 3.74 3.79 3.76 3.75 3.79 3.77 3.75
115
T.C. 44.1 41.1 37.8 44.9 41.6 38.4 45.6 42.2 39.1
S.C. 30.8 29.8 28.1 33.1 31.9 30.2 35.4 34.1 32.3
K.W 4.18 4.16 4.15 4.19 4.16 4.15 4.21 4.16 4.15
125
T.C. 41.7 38.7 35.5 42.5 39.2 36.0 43.3 39.7 36.6
S.C. 29.8 28.8 27.1 32.2 31.0 29.2 34.6 33.1 31.3
K.W 4.59 4.56 4.56 4.60 4.56 4.55 4.62 4.56 4.55
NOTE: ALL CAPACITIES INCLUDE INDOOR FAN HEAT AT 1250 BTUH/1000 CFM.
Air Handler Coil
T.C. S.C. KW
N1AHD2006 G2FD060S24 0.99 0.99 1.00
N1AHD2006 G2FD061H24 1.00 1.00 1.00
N1VSC16 G2FD048S21 0.98 0.97 0.95
N1VSD20 G2FD060S24 1.00 0.99 0.96
F2FP060 0.98 0.97 1.04
F2FV060 1.01 1.02 0.91
G1NF060SOF 0.99 0.96 0.99
G1UA048S21,24 0.96 0.95 0.99
G1UA060S21,24 0.99 0.99 1.00
G2FD048S21,24 0.97 0.97 0.99
G2FD060S24 0.99 0.99 1.00
G2FD061H24 1.00 1.00 1.00
G1FA048S21,24 0.96 0.95 0.99
G1FA060S21,24 0.99 0.99 1.00
G1HD048S 0.96 0.94 1.00
G1NA042S24W 0.99 0.96 0.99
GNA048S21D 0.94 0.85 0.97
Variable Speed
Furnace
Coil
T.C. S.C. KW
P1DUC20V G1FA060S21 0.99 0.99 0.97
P1DUC20V G1UA060S21 0.99 0.99 0.97
P1DUC20V G2FD048S21 0.97 0.97 0.96
P1XDD20V G2FD060S24 1.00 0.99 0.98
